Design
Product colour: Black, White
Housing material: Metal
Mounting type: Ceiling/wall
International Protection (IP) code: IP67
Form factor: Tube/dome
Power
Power source type: DC, PoE
Power consumption (max): 6.9 W
DC output voltage: 12
Security
Mirror: Yes
Built-in siren: Yes
HTTPS encryption: Yes
Intelligent Video Surveillance (IVS) system features: Tripwire
IP address filtering: Yes
Video motion detection: Yes
Security algorithms: HTTPS
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Management features
Management software: Smart PSS, DSS, DMSS
Web browser: Yes
Weight & dimensions
Height: 108.3 mm
Diameter: 12.2 cm
Weight: 740 g
Network
Bluetooth: No
Ethernet LAN: Yes
Wi-Fi: No
Networking standards: IEEE 802.1x, IEEE 802.3af
Number of users: 20 user(s)
Streaming method: Multicast
Quality of Service (QoS) support: Yes
Ethernet interface type: Fast Ethernet
System requirements
Mobile operating systems supported: Android, iOS
Certification: LVD: EN62368-1; EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Performance
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Alarm input/output: Yes
Placement supported: Indoor & outdoor
Type: IP security camera
Day/night mode: Yes
Packaging content
Number of cameras: 1
Audio
Audio output channels: 1 channels
Voice codecs: G.711a, G.726, G.711Mu
Audio input channels: 1 channels
Signal-to-Noise Ratio (SNR): 56 dB
Built-in microphone: Yes
Storage
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
ROM capacity: 128 MB
Built-in HDD: No
Internal memory: 512 MB
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 78°
Angle of rotation: 360°
Camera shutter type: Electronic
Camera shutter speed: 1/3 - 1/100000 s
White balance: Outdoor, Manual, Auto, Natural, Street lamp
Camera tilt control: Yes
Pan range: 0 - 360°
Minimum illumination: 0.002 lx
Adjustment shutter speed: Auto/Manual
Camera pan control: Yes
Lens viewing angle, vertical: 57°
Lens viewing angle, diagonal: 131°
Lens viewing angle, horizontal: 109°
Image sensor
Number of sensors: 1
Sensor type: CMOS
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Progressive scan: Yes
Video
Back Light Compensation (BLC): Yes
Video compression formats: H.264B, H.265, H.264H, H.264, M-JPEG
Video formats supported: H.264+, H.265+
Bit rate: H.264: 32 Kbps–8192 Kbps, H.265: 19 Kbps– 8192 Kbps
Supported graphics resolutions: 352 x 288, 352 x 240, 640 × 480, 704 x 480, 704 x 576, 1280 x 960, 1920 × 1080
Frame rate: 30 fps
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels: 2 MP
Video streaming: Yes
Noise reduction technology: 3D noise reduction
Privacy masking: Yes
Highlight Compensation (HLC): Yes
Maximum resolution: 1920 x 1080 pixels
Region of Interest (ROI) encoding: Yes
Gain control type: Auto/Manual
Noise reduction: Yes
Night vision
Night vision distance: 40 m
Number of illumination LEDs: 2
Night vision: Yes
Lens system
Closest focusing distance: 0.8 m
Fixed focal length: 2.8 mm
Identify distance (wide): 4.4 m
Observe distance (wide): 17.6 m
Number of lenses: 1
Detect distance (wide): 44.1 m
Maximum aperture number: 1.5
Recognize distance (wide): 8.8 m
