Processor
Built-in processor: Yes
Certification: FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2:
2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021;EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 CE-LVD: EN 62368-1: 2014
Features
Rack mounting: Yes
Rack capacity: 1.5U
Product colour: Black
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 13 W
AC input frequency: 50 - 60 Hz
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Package weight: 6.11 kg
Package depth: 500 mm
Package width: 530 mm
Package height: 210 mm
Height: 70 mm
Weight: 4.74 kg
Width: 440 mm
Depth: 415.1 mm
Performance
Alarm output channels: 6
Video formats supported: H.265, H.264+, H.265+, H.264
Audio formats supported: PCM, G.711 A-law, G.726
Video input channels: 32 channels
Alarm input channels: 16
Face detection: Yes
Operating system installed: Embedded LINUX
Multi-screen: Yes
Number of fans: 1 fan(s)
Video motion detection: Yes
Maximum resolution: 1920 x 1080 pixels
Wireless LAN features
Wi-Fi: No
Storage
Number of HDDs supported: 4
Maximum storage capacity: 16 TB
HDD interface: SATA III
Ports & interfaces
Audio RCA inputs: 1
eSATA: Yes
VGA (D-Sub) output ports: 2
RS-485 ports: 1
Audio RCA outputs: 1
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
HDMI ports quantity: 2
Ethernet LAN (RJ-45) ports: 2
USB 2.0 ports quantity: 1
DVI ports quantity: 2
RS-232 interface: Yes
eSATA ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
