Technical details
File format system: FAT 12/16/32
Pause function: Yes
Security features: Removable front
Reverse connection: Y
Fader: Yes
Tuner enhancements: Auto tuning, Auto scan
Key illumination colour: Red
Operational conditions
Operating temperature (T-T): -10 - 60 °C
Storage temperature (T-T): -30 - 85 °C
Weight & dimensions
Weight: 600 g
Width: 182 mm
Depth: 100 mm
Height: 53 mm
Performance
Product colour: Black
RDS features: REG, TI, PTY1, PTY, AF, CT, PS, RT
Audio output channels: 4.1 channels
Mobile operating systems supported: Android 4.2, Android 4.4, Android 7.1, Android 4.3, Android 5.0, Android 4.2.1, Android 4.1, Android 7.1.2, Android 4.2.2, Android 6.0, Android 5.1
Impedance: 75 Ω
Frequency range: 20 - 20000 Hz
Equalizer bands quantity: 3
DIN size: 1 DIN
CD player: No
Firmware upgradeable: Yes
Clock mode: 12h/24h
Smartphone/tablet remote support: Yes
Steering mounting remote control capability: Yes
Output power: 200 W
Signal-to-Noise Ratio (SNR): 105 dB
Maximum power per channel: 50 W
Low pass filter: Yes
Ready for iPod: No
Dimmer: Yes
Integrated clock: Yes
Bass adjustment: No
Equalizer: Yes
Volume control: Rotary
Equalizer customizable: Yes
Disc types supported: No
Removable front panel: Yes
Packaging data
Package weight: 900 g
Packaging content
Mounting brackets included: Yes
Display
Detachable display: Yes
On Screen Display (OSD) languages: English, Russian, Spanish
LED backlight: Yes
ID3 Tag display: Yes
Number of OSD languages: 3
Display number of lines: 2 lines
Built-in display: Yes
Display type: LCD
Display illumination: Yes
On Screen Display (OSD): Yes
Illumination colour: White
Multimedia
CD-R playback: No
Audio formats supported: FLAC, WAV, MP3, PCM, WMA
USB direct playback: Yes
Audio D/A Converter (DAC): 24 bit
MP3 playback: Yes
CD-RW playback: No
Ports & interfaces
Pre out port: Yes
USB ports quantity: 1
Headphone connectivity: 3.5mm
Bluetooth: No
USB connector type: USB Type-A
Subwoofer out: Yes
Illuminated USB port: Yes
AUX in: Yes
Android Auto support: Yes
USB version: 2.0
USB port: Yes
USB port position: Front
Line outputs (RCA): 1
ISO connector: Yes
Radio
FM radio: Yes
