Design
Form factor: Bullet
Number of illumination LEDs: 2
Housing material: Metal
International Protection (IP) code: IP67
Product colour: White
Mounting type: Ceiling/Wall/Pole
Power
Power consumption (max): 6.4 W
DC output voltage: 12
Power source type: DC
Security
Mirror: Yes
Display language: Polish, English, Chinese, French, German, Spanish, Portuguese, Italian, Korean, Japanese, Russian
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Weight: 580 g
Package weight: 740 g
Height: 104.8 mm
Network
Bluetooth: No
Ethernet LAN: No
Wi-Fi: No
Certification: CE (EN55032:2015, EN 61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017)FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Performance
Day/night mode: Yes
Operating modes: AHD, CVI, TVI, CVBS
Connectivity technology: Wired
Dynamic range: 130 dB
Wide Dynamic Range (WDR): Yes
Placement supported: Indoor/outdoor
Packaging content
Number of cameras: 1
Mounting kit: Yes
Audio
Signal-to-Noise Ratio (SNR): 65 dB
Built-in microphone: Yes
Management via coaxial cable : Y
Storage
Built-in HDD: No
Ports & interfaces
BNC output ports: 1
Audio output: 1
Camera
Angle of rotation: 360°
Pan range: 0 - 360°
Camera shutter type: Electronic
Camera shutter speed: 1/25 - 1/100000 s
Tilt angle range: 0 - 78°
Minimum illumination: 0.002 lx
White balance: Auto
Lens viewing angle, vertical: 53°
Lens viewing angle, diagonal: 123°
Lens viewing angle, horizontal: 102°
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Video
Supported graphics resolutions: 960 x 480, 960 x 576, 1920 x 1080 (HD 1080)
Privacy masking: Yes
Gain control type: Auto/Manual
Frame rate: 30 fps
Analog signal format system: NTSC, PAL
Total megapixels: 2 MP
Supported video modes: 480p, 1080p, 576p
Smart IR: Yes
Maximum resolution: 1920 x 1080 pixels
Noise reduction: Yes
Highlight Compensation (HLC): Yes
Back Light Compensation (BLC): Yes
Noise reduction technology: 3D noise reduction
Recording in colour: Yes
Night vision
LED type: IR
Number of illumination LEDs: 2
Night vision distance: 60 m
Night vision: Yes
Lens system
Auto focus: Yes
Maximum aperture number: 1.5
Number of lenses: 1
