Technical details
Number of video streams: 2
Design
Mounting type: Ceiling/wall
Protection features: Waterproof
IK code: IK10
Product colour: White
Form factor: Dome
International Protection (IP) code: IP67
Housing material: Metal
Power
DC output voltage: 12
Power consumption (Power over Ethernet (PoE)): 7.3 W
Power source type: DC, PoE
Power consumption (max): 6.4 W
Power consumption (typical): 2.7 W
Security
Video motion detection: Yes
Intelligent Video Surveillance (IVS) system features: Intrusion, Tripwire
Alarm output channels: 1
Privacy protection: Yes
Mirror: Yes
Network access storage (NAS): Yes
Alarm input channels: 1
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Management features
Web browser: Yes
Management software: Smart PSS, DSS, DMSS
Weight & dimensions
Weight: 510 g
Height: 93.4 mm
Diameter: 12.2 cm
Network
Number of users: 20 user(s)
Client interoperability: ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
Networking standards: IEEE 802.3af
Bluetooth: No
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Wi-Fi: No
System requirements
Mobile operating systems supported: Android, iOS
Certification: CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
Performance
Day/night mode: Yes
Placement supported: Indoor & outdoor
Alarm input/output: Yes
Dynamic range: 120 dB
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Packaging data
Package weight: 670 g
Packaging content
Number of cameras: 1
Audio
Voice codecs: PCM, G.711Mu, G.711a, G.726
Built-in microphone: Yes
Audio output channels: 1.0 channels
Signal-to-Noise Ratio (SNR): 56 dB
Audio input channels: 1.0 channels
Storage
ROM capacity: 128 MB
Maximum memory card size: 256 GB
Built-in HDD: No
RAM capacity: 256 MB
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 58 - 18°
Lens viewing angle, horizontal: 113 - 31°
Lens viewing angle, diagonal: 138 - 36°
Number of Privacy masking areas: 4
Tilt angle range: 0 - 75°
Angle of rotation: 355°
Camera shutter type: Electronic
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0 lx
White balance: Auto, Manual, Street lamp, Natural, Outdoor
Adjustment shutter speed: Auto/Manual
Pan range: 0 - 355°
Other features
Browser supported: IE: IE8, IE9, IE11 Chrome Firefox, Safari
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Number of sensors: 1
Video
Privacy masking: Yes
Smart IR: Yes
Noise reduction: Yes
Video streaming: Yes
Video compression formats: H.265+, H.264, H.264+, H.264B, H.265
Gain control type: Auto/Manual
Region of Interest (ROI) encoding: Yes
Noise reduction technology: 3D noise reduction
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Supported graphics resolutions: 1280 x 720 (HD 720), 2688 x 1512, 352 x 240, 2304 x 1296, 704 x 576, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 3072 x 1728, 3840 x 2160, 704 x 480, 640 x 480 (VGA), 3072 x 2048, 352 x 288, 2880 x 1620
Maximum resolution: 3840 x 2160 pixels
Bit rate: 12 Kbps - 8192 Kbps
Back Light Compensation (BLC): Yes
Total megapixels: 8 MP
Highlight Compensation (HLC): Yes
Night vision
Night vision: Yes
Night vision distance: 40 m
Number of illumination LEDs: 2
LED type: IR
Lens system
Observe distance (tele): 112 m
Identify distance (tele): 28 m
Recognize distance (tele): 56 m
Focal length range: 2.7 - 13.5 mm
Recognize distance (wide): 17.1 m
Identify distance (wide): 8.5 m
Closest focusing distance: 0.8 m
Observe distance (wide): 34.1 m
Maximum aperture number: 1.5
Detect distance (wide): 85.3 m
Number of lenses: 1
Detect distance (tele): 280 m
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
