Design
Product colour: White
Housing material: Metal, Plastic
Mounting type: Ceiling
International Protection (IP) code: IP67
Form factor: Dome
Degree of protection IK: IK10
Power
Power consumption (typical): 3.8 W
Power source type: DC, PoE
Power consumption (Power over Ethernet (PoE)): 7.2 W
Power consumption (max): 5.9 W
DC output voltage: 12, 48
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -40 - 60 °C
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Weight: 423 g
Depth: 111 mm
Height: 64.8 mm
Width: 111 mm
Network
Bluetooth: No
Networking standards: IEEE 802.3af, IEEE 802.1x
Wi-Fi: No
Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
4G LTE: No
System requirements
Mobile operating systems supported: Android, iOS
Performance
Signal-to-Noise Ratio (SNR): 56 dB
Type: IP security camera
Placement supported: External / Internal
Wide Dynamic Range (WDR): 120 dB
Connectivity technology: Wired
Packaging content
Number of cameras: 1
Audio
Two-way talk: Yes
Built-in microphone: Yes
Audio codecs: G.711a / G.711Mu / G.723 / G.726 / PCM
Built-in loudspeaker: Yes
Storage
ROM capacity: 128 MB
RAM capacity: 512 MB
Ports & interfaces
Number of memory card slots: 1
Compatible memory cards: MicroSD (TransFlash), MicroSDXC, MicroSDHC
Ethernet LAN (RJ-45) ports: 1
Alarm input/output: No
Maximum memory card size: 256 GB
Audio RCA outputs: 1
RCA input: 1
Camera
Horizontal rotation angle: 0 - 355°
Adjustment shutter speed: Auto/Manual
Viewing angle, diagonal: 132°
Vertical rotation angle: -20 - 70°
Minimum illumination: 0.005 lx
Camera shutter speed: 1/3 - 1/100000 s
People detection : Yes
Motion detection : Yes
Lens viewing angle, vertical: 58°
Lens viewing angle, horizontal: 111°
Image sensor
Progressive scan: Yes
Sensor type: HD CMOS
Number of sensors: 1
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Bit rate: 3 Kbp - 8192Kbps
Video streaming: Yes
Supported graphics resolutions: 2560 x 1440, 352 x 288, 704 x 576, 1280 x 960, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 352 x 240, 2304 x 1296, 704 x 480, 2688 x 1520, 1280 x 720, 2880 x 1620, 2960 x 1668
Video compression formats: M-JPEG, H.265, H.264+, H.264B, H.265+, AI Coding, H.264H, H.264
Frame rate: 25 / 30 fps
Total megapixels: 5 MP
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Maximum resolution: 2960 x 1668 pixels
Noise reduction technology: 3D noise reduction
Night vision
Night vision: Yes
LED type: IR
Night vision distance: 30 m
Number of illumination LEDs: 2
Lens system
Identify distance (wide): 6.4 m
Lens type: Fixed focal length lens
Detect distance (wide): 63.6 m
Number of lenses: 1
Focal length range: 2.8 mm
Maximum aperture number: 1.6
Closest focusing distance: 0.9 m
Recognize distance (wide): 12.7 m
Aperture type: Permanent
