Design
Housing material: Metal, Plastic
Form factor: Tube/dome
Product colour: White
Mounting type: Wall/ceiling
International Protection (IP) code: IP67
Power
Power consumption (typical): 1.6 W
DC output voltage: 12
Power consumption (max): 3.8 W
Power consumption (Power over Ethernet (PoE)): 4.4 W
Power source type: DC, PoE
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Width: 121.9 mm
Depth: 121.9 mm
Height: 99.1 mm
Weight: 460 g
Network
Networking standards: IEEE 802.3af
Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
4G LTE: No
Bluetooth: No
Wi-Fi: No
System requirements
Mobile operating systems supported: iOS, Android
Performance
Signal-to-Noise Ratio (SNR): 56 dB
Type: IP security camera
Connectivity technology: Wired
Wide Dynamic Range (WDR): 120 dB
Placement supported: Outdoor
Packaging content
Number of cameras: 1
Audio
Audio codecs: PCM, G.711a G.711Mu, G.726
Two-way talk: N
Built-in microphone: Yes
Built-in loudspeaker: No
Storage
ROM capacity: 128 MB
RAM capacity: 128 MB
Camera
Adjustment shutter speed: Auto/Manual
Camera shutter speed: 1/3 - 1/100000 s
Viewing angle, diagonal: 127°
Horizontal rotation angle: 0 - 360°
Minimum illumination: 0.002 lx
Vertical rotation angle: 0 - 78°
Lens viewing angle, horizontal: 107°
Motion detection : Yes
People detection : Yes
Lens viewing angle, vertical: 56°
Image sensor
Sensor type: HD CMOS
Progressive scan: Yes
Number of sensors: 1
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Video
Video streaming: Yes
Video compression formats: H.264B, H.264H, H.264, H.265+, M-JPEG, H.264+, H.265
Frame rate: 25 / 30 fps
Maximum resolution: 1920 x 1080 pixels
Total megapixels: 2 MP
Night vision
Night vision distance: 30 m
Number of illumination LEDs: 1 / 1
LED type: IR / White light LED
Night vision: Yes
Lens system
Closest focusing distance: 0.7 m
Number of lenses: 1
Lens type: Fixed focal length lens
Focal length range: 2.8 mm
Maximum aperture number: 1.6
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste.
