Features
Processor frequency: 1300 MHz
Flash memory: 128 MB
Internal memory: 256 MB
Internal memory type: DDR3
Processor cores: 2
Processor model: MediaTek MT7981B
Processor manufacturer: MediaTek
Design
LED indicators: Yes
Product colour: Grey, White
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 20 - 95%
Operating temperature (T-T): 0 - 40 °C
Management features
MAC address filtering: Yes
IPv4 & IPv6 features: IPv6 SSH, IPv6 Telnet
Dynamic Frequency Selection (DFS): Yes
Event logging: Yes
Backup function: Yes
Wireless meshing: Yes
Cloud-managed: Yes
Command-line interface (CLI): Yes
Weight & dimensions
Height: 128 mm
Weight: 208 g
Depth: 41 mm
Width: 68 mm
Network
Networking standards: IEEE 802.11r, IEEE 802.11v, IEEE 802.11ax, IEEE 802.11k
Security algorithms: WPA2-PSK, WPA3-PSK, OWE, WPA2-Enterprise, WEP, WPA-PSK, WPA3-Enterprise
WLAN data transfer rate (first band): 574 Mbit/s
Wi-Fi: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Wi-Fi data rate (max): 3000 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Modulation: OFDMA
WLAN data transfer rate (second band): 2402 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi standards: Wi-Fi 6 (802.11ax)
MU-MIMO technology: Yes
Performance
Airtime Fairness (ATF): Yes
Ethernet LAN data rates: 1000 Mbit/s
Type: Network repeater
Firmware upgradeable: Yes
Number of devices supported: 256
Guest access: Yes
Web-based setup wizard: Yes
Mobile app support: Yes
WPS push button: Yes
Data transfer rate: 3000 Mbit/s
Number of guest networks (2.4 GHz): 7
BeamForming: Yes
Direct or cloud access via KeenDNS: Yes
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna type: External
Antennas quantity: 2
