Features
Processor cores: 2
Processor model: MediaTek MT7981B
Built-in processor: Yes
Internal memory type: DDR4
Flash memory: 128 MB
Firmware upgradeable: Yes
Processor frequency: 1300 MHz
WireGuard: Yes
Cloudflare DNS: Yes
AdGuard ad blocker: Yes
Internal memory: 512 MB
Processor manufacturer: MediaTek
Design
Wall mountable: Yes
LED indicators: LAN, Power, WLAN
Housing material: Plastic
Product type: Tabletop router
Product colour: White
Power
AC input frequency: 50/60 Hz
Power source type: AC
AC input voltage: 100 - 240 V
Output current: 1.5 A
Output voltage: 12 V
Security
Security algorithms: WPA3-PSK, OWE, WPA2-Enterprise, WPA2-PSK, WPA-PSK, WPA3-Enterprise, WEP
Guest access: Yes
MAC address filtering: Yes
DoS attack prevention: Yes
System event log: Yes
Firewall security: SPI
Parental control: Yes
Firewall: Yes
Schedule access: Yes
Network address translation (NAT): Yes
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 95%
Management features
MU-MIMO technology: Yes
Quality of Service (QoS) support: Yes
Web-based management: Yes
Number of data streams: 3x3
Wi-Fi Multimedia (WMM)/(WME): Yes
WPS push button: Yes
HTTPS security for access via KeenDNS: Yes
Command-line interface (CLI): Yes
Intelligent Mesh technology: Yes
MIMO: Yes
Cloud-managed: Yes
Bandwidth control: Yes
Captive portal: Yes
Web-based setup wizard: Yes
Direct or cloud access via KeenDNS: Yes
Backup function: Yes
Traffic statistics: Yes
Weight & dimensions
Depth: 170 mm
Height: 42 mm
Weight: 385 g
Width: 170 mm
VPN support: PPTP (client/server), L2TP over IPSec client/server, OpenVPN client/server, SSTP client/server, IPsec VPN (client/server)
Network
Networking standards: IEEE 802.11v, IEEE 802.1Q, IEEE 802.11ax, IEEE 802.11a, IEEE 802.11b, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11g, IEEE 802.11n
Ethernet LAN: Yes
Number of guest networks (2.4 GHz): 7
Ethernet LAN data rates: 1000 Mbit/s, 100, 2500, 10
Port forwarding: Yes
L2TP/PPTP data rate: 2400 Mbit/s
IPoE/PPPoE data rate: 4800 Mbit/s
Ethernet LAN interface type: 2.5 Gigabit Ethernet
PPPoE/PPTP/L2TP pass-through: Yes
Ping check: Yes
Internet connection backup: Yes
SSID-based VLAN assignment: Yes
Cabling technology: 10/100/1000/2500Base-T
Dynamic DNS (DDNS): Yes
IntelliQoS: Yes
Routing table: DHCP, Manual
VPN server: OpenVPN
Number of guest networks (5 GHz): 7
Policy-based routing: Yes
WireGuard throughput: 460 Mbit/s
System requirements
Mobile operating systems supported: iOS, Android
Packaging data
Number of products included: 1 pc(s)
Packaging content
Cables included: LAN (RJ-45)
Quick start guide: Yes
AC adapter included: Yes
Wireless LAN features
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band): 300 Mbit/s
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (second band): 2402 Mbit/s
WLAN data transfer rate (max): 3000 Mbit/s
Protocols
DHCP client: Yes
IPv4 & IPv6 features: IPv6 SSH, IPv6 Telnet, Dual stack IPv4/IPv6
Supported network protocols: IPoE, PPPoE, PPTP, L2TP, 802.1x
UDP-to-HTTP proxy: Yes
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
DC-in jack: Yes
USB port: No
Antenna
Antennas quantity: 5
Antenna design: Internal
WAN connection
SIM card slot: No
WAN connection type: RJ-45, WISP
DSL WAN: No
3G/4G USB modem compatibility: No
Ethernet WAN: Yes
Supported WAN type: Multi-WAN
Supported protocols: EoIP, IP-IP, GRE
Other features
Number of users: 256 user(s)
Mobile network
USSD request support: Yes
