Features
Processor frequency: 1300 MHz
Firmware upgradeable: Yes
Internal memory type: DDR3
Internal memory: 512 MB
Processor cores: 2
Processor model: MediaTek MT7981B
Built-in processor: Yes
Flash memory: 256 MB
Processor manufacturer: MediaTek
WireGuard: Yes
AdGuard ad blocker: Yes
Cloudflare DNS: Yes
Design
Product colour: White, Grey
Product type: Tabletop router
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Output voltage: 12 V
Power source type: AC
Output current: 2 A
Security
DoS attack prevention: Yes
Firewall: Yes
Parental control: Yes
Guest access: Yes
Schedule access: Yes
Network address translation (NAT): Yes
MAC address filtering: Yes
IGMP snooping: Yes
System event log: Yes
Security algorithms: WPA3-PSK, OWE, WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise, WPA-PSK, WEP
Firewall security: SPI
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 95%
Management features
Captive portal: Yes
Web-based setup wizard: Yes
Traffic statistics: Yes
Cloud-managed: Yes
WPS push button: Yes
MU-MIMO technology: Yes
Bandwidth control: Yes
Command-line interface (CLI): Yes
MIMO: Yes
Direct or cloud access via KeenDNS: Yes
Web-based management: Yes
Quality of Service (QoS) support: Yes
Backup function: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Intelligent Mesh technology: Yes
Number of data streams: 2x2
HTTPS security for access via KeenDNS: Yes
Weight & dimensions
Depth: 159 mm
Width: 217 mm
Weight: 600 g
Height: 45 mm
VPN support: PPTP (client/server), L2TP over IPSec client/server, OpenVPN client/server, SSTP client/server, IPsec VPN (client/server)
Network
Dynamic DNS (DDNS): Yes
Policy-based routing: Yes
Built-in FTP server: Yes
Support Samba (storage): Yes
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Networking standards: IEEE 802.1Q, IEEE 802.11ax, IEEE 802.11v, IEEE 802.11g, IEEE 802.11ac, IEEE 802.11k, IEEE 802.11b, IEEE 802.11r, IEEE 802.11h
L2TP/PPTP data rate: 800 Mbit/s
Routing table: Manual, DHCP
PPPoE/PPTP/L2TP pass-through: Yes
Ping check: Yes
IntelliQoS: Yes
WireGuard throughput: 460 Mbit/s
IPoE/PPPoE data rate: 1800 Mbit/s
Internet connection backup: Yes
Ethernet LAN interface type: Gigabit Ethernet
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
Port forwarding: Yes
Media server: Yes
VPN server: OpenVPN
System requirements
Mobile operating systems supported: iOS, Android
Packaging data
Number of products included: 1 pc(s)
Packaging content
Quick start guide: Yes
AC adapter included: Yes
Cables included: LAN (RJ-45)
Wireless LAN features
WLAN data transfer rate (second band): 2402 Mbit/s
WLAN data transfer rate (first band): 574 Mbit/s
Modulation: OFDMA
Wi-Fi standards: Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max): 3000 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Protocols
IPv4 & IPv6 features: Dual stack IPv4/IPv6, IPv6 SSH, IPv6 Telnet
DHCP client: Yes
Universal Plug and Play (UPnP): Yes
DHCP server: Yes
Supported network protocols: IPoE, PPPoE, PPTP, L2TP, 802.1x
UDP-to-HTTP proxy: Yes
Ports & interfaces
DC-in jack: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB port: Yes
Ethernet LAN (RJ-45) ports: 5
Antenna
Antenna design: External
Antennas quantity: 4
Detachable antenna(s): Yes
Antenna connector type: SMA
Antenna gain level (max): 4 dBi
WAN connection
3G/4G USB modem compatibility: Yes
WAN connection type: RJ-45, WISP
Ethernet WAN: Yes
SIM card slot: Yes
Mobile network
Mobile network generation: 4G
3G bands supported: 900, 2100 MHz, 850
SIM card type: NanoSIM
4G bands supported: 900, 850, 2500, 2300, 800, 1800, 2600 MHz, 2100
4G data rate (max): 300 Mbit/s
USSD request support: Yes
3G standards: HSDPA, WCDMA, HSPA+, HSUPA
Short Message Service (SMS): Yes
3G: Yes
4G standard: LTE-TDD & LTE-FDD
Modem chipset: ASR1826
