Features
Processor cores: 2
Processor model: MediaTek MT7981B
Internal memory type: DDR4
Built-in processor: Yes
Flash memory: 128 MB
Processor manufacturer: MediaTek
Processor frequency: 1300 MHz
Firmware upgradeable: Yes
Internal memory: 512 MB
Cloudflare DNS: Yes
WireGuard: Yes
AdGuard ad blocker: Yes
Design
LED indicators: LAN, Power, WLAN
Product type: Tabletop router
Product colour: White
Power
Output current: 1 A
Power source type: AC
Output voltage: 12 V
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Security
System event log: Yes
Access Control List (ACL): Yes
Guest access: Yes
Security algorithms: WPA3-Enterprise, WPA2-PSK, WPA2-Enterprise, OWE, WPA3-PSK, WPA-PSK, WEP
Firewall security: SPI
IGMP snooping: Yes
Parental control: Yes
Firewall: Yes
DoS attack prevention: Yes
DDoS protection: Yes
Network address translation (NAT): Yes
Schedule access: Yes
MAC address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 20 - 95%
Operating temperature (T-T): 0 - 40 °C
Management features
WPS push button: Yes
Backup function: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Web-based setup wizard: Yes
Captive portal: Yes
Cloud-managed: Yes
MU-MIMO technology: Yes
Quality of Service (QoS) support: Yes
Bandwidth control: Yes
Intelligent Mesh technology: Yes
Traffic statistics: Yes
Web-based management: Yes
Command-line interface (CLI): Yes
MIMO: Yes
HTTPS security for access via KeenDNS: Yes
Direct or cloud access via KeenDNS: Yes
Weight & dimensions
Height: 45 mm
Depth: 118 mm
Width: 160 mm
Weight: 324 g
VPN support: PPTP (client/server), L2TP over IPSec client/server, OpenVPN client/server, SSTP client/server, IPsec VPN (client/server)
Network
SSID-based VLAN assignment: Yes
Ethernet LAN: Yes
Port forwarding: Yes
Automatic channel selection: Yes
Ethernet LAN interface type: Gigabit Ethernet
Dynamic DNS (DDNS): Yes
Cabling technology: 10/100/1000Base-T(X)
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.11k, IEEE 802.1Q, IEEE 802.11ax, IEEE 802.11v, IEEE 802.11ac, IEEE 802.11a, IEEE 802.11b
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Policy-based routing: Yes
Number of guest networks (5 GHz): 7
Number of guest networks (2.4 GHz): 7
Internet connection backup: Yes
IPoE/PPPoE data rate: 1800 Mbit/s
L2TP/PPTP data rate: 900 Mbit/s
Routing table: Manual, DHCP
Ping check: Yes
IntelliQoS: Yes
WireGuard throughput: 460 Mbit/s
PPPoE/PPTP/L2TP pass-through: Yes
System requirements
Mobile operating systems supported: iOS, Android
Packaging data
Number of products included: 1 pc(s)
Packaging content
Cables included: LAN (RJ-45)
Quick start guide: Yes
AC adapter included: Yes
Wireless LAN features
WLAN data transfer rate (max): 3000 Mbit/s
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (first band): 300 Mbit/s
Wi-Fi standards: Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rate (second band): 2402 Mbit/s
Protocols
Supported network protocols: IPoE, PPPoE, PPTP, L2TP, 802.1x
Universal Plug and Play (UPnP): Yes
IPv4 & IPv6 features: Dual stack IPv4/IPv6, IPv6 Telnet, IPv6 SSH
DHCP server: Yes
DHCP client: Yes
UDP-to-HTTP proxy: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB port: No
Antenna
Antennas quantity: 2
Antenna design: External
WAN connection
3G/4G USB modem compatibility: No
SIM card slot: No
WAN connection type: RJ-45, WISP
Ethernet WAN: Yes
DSL WAN: No
Supported WAN type: Multi-WAN
Supported protocols: EoIP, IP-IP, GRE
Other features
Number of users: 256 user(s)
Mobile network
USSD request support: Yes
