Features
Firmware upgradeable: Yes
Internal memory type: DDR3
Processor cores: 2
Processor manufacturer: MediaTek
Processor frequency: 900 MHz
Processor model: EcoNet EN7528DU
Cloudflare DNS: Yes
Flash memory: 128 MB
Built-in processor: Yes
WireGuard: Yes
Internal memory: 256 MB
AdGuard ad blocker: Yes
Design
Product colour: White, Grey
LED indicators: LAN, Power, WAN
Product type: Tabletop router
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Output voltage: 12 V
Power source type: AC
Output current: 1.5 A
Security
Network address translation (NAT): Yes
MAC address filtering: Yes
Security algorithms: WPA2-PSK, WPA2-Enterprise, OWE, WPA3-Enterprise, WPA-PSK, WPA3-PSK, WEP
Schedule access: Yes
DoS attack prevention: Yes
Firewall: Yes
System event log: Yes
Firewall security: SPI
Parental control: Yes
IGMP snooping: Yes
Guest access: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 95%
Management features
Web-based management: Yes
MIMO: Yes
Quality of Service (QoS) support: Yes
Number of data streams: 2x2
Bandwidth control: Yes
MU-MIMO technology: Yes
Intelligent Mesh technology: Yes
HTTPS security for access via KeenDNS: Yes
Direct or cloud access via KeenDNS: Yes
WPS push button: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Captive portal: Yes
Web-based setup wizard: Yes
Cloud-managed: Yes
Backup function: Yes
Traffic statistics: Yes
Command-line interface (CLI): Yes
Weight & dimensions
Weight: 270 g
Width: 159 mm
Height: 29 mm
Depth: 110 mm
VPN support: PPTP (client/server), L2TP over IPSec client/server, OpenVPN client/server, SSTP client/server, IPsec VPN (client/server)
Network
Networking standards: IEEE 802.11ac, IEEE 802.11a, IEEE 802.11r, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.11k, IEEE 802.11v, IEEE 802.11b
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Ethernet LAN interface type: Gigabit Ethernet
Routing table: Manual, DHCP
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
PPPoE/PPTP/L2TP pass-through: Yes
Number of guest networks (5 GHz): 7
Support Samba (storage): Yes
L2TP/PPTP data rate: 800 Mbit/s
Number of guest networks (2.4 GHz): 7
IPoE/PPPoE data rate: 1800 Mbit/s
Media server: Yes
IntelliQoS: Yes
Port forwarding: Yes
Internet connection backup: Yes
VPN server: OpenVPN
Ping check: Yes
Dynamic DNS (DDNS): Yes
Built-in FTP server: Yes
WireGuard throughput: 130 Mbit/s
Policy-based routing: Yes
System requirements
Mobile operating systems supported: iOS, Android
Packaging data
Number of products included: 1 pc(s)
Packaging content
Quick installation guide: Yes
Quick start guide: Yes
AC adapter included: Yes
Cables included: LAN (RJ-45)
Wireless LAN features
WLAN data transfer rate (max): 1200 Mbit/s
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band): 300 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (second band): 867 Mbit/s
Protocols
DHCP client: Yes
IPv4 & IPv6 features: IPv6 SSH, Dual stack IPv4/IPv6, IPv6 Telnet
Supported network protocols: IPoE, PPPoE, PPTP, L2TP, 802.1x
Universal Plug and Play (UPnP): Yes
DHCP server: Yes
UDP-to-HTTP proxy: Yes
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 4
USB 2.0 ports quantity: 1
USB port: No
Antenna
Antennas quantity: 4
Antenna design: External
WAN connection
Ethernet WAN: Yes
3G/4G USB modem compatibility: Yes
DSL WAN: No
WAN connection type: RJ-45, WISP
SIM card slot: No
Supported WAN type: Multi-WAN
Supported protocols: EoIP, IP-IP, GRE
Other features
Number of users: 199 user(s)
Mobile network
USSD request support: Yes
