Features
Flash memory: 32 MB
Built-in processor: Yes
Processor manufacturer: MediaTek
Internal memory: 128 MB
Internal memory type: DDR2
Processor frequency: 575 MHz
Processor model: MediaTek MT7628N
Firmware upgradeable: Yes
Cloudflare DNS: Yes
WireGuard: Yes
AdGuard ad blocker: Yes
Design
Product type: Tabletop router
LED indicators: LAN, Power, WLAN
Product colour: White, Grey
Power
Output voltage: 5 V
Output current: 1 A
Power source type: AC
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Security
Firewall: Yes
Firewall security: SPI
System event log: Yes
Guest access: Yes
Parental control: Yes
IGMP snooping: Yes
DoS attack prevention: Yes
Schedule access: Yes
Network address translation (NAT): Yes
Stateful Packet Inspection (SPI): Yes
Security algorithms: WPA2-PSK, WPA-PSK, WPA3-Enterprise, WPA3-PSK, OWE, WPA2-Enterprise, WEP
MAC address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 20 - 95%
Operating temperature (T-T): 0 - 40 °C
Management features
Web-based setup wizard: Yes
Traffic statistics: Yes
Backup function: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Captive portal: Yes
WPS push button: Yes
Cloud-managed: Yes
Command-line interface (CLI): Yes
Intelligent Mesh technology: Yes
Bandwidth control: Yes
HTTPS security for access via KeenDNS: Yes
Web-based management: Yes
Direct or cloud access via KeenDNS: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 107 mm
Depth: 91 mm
Height: 26 mm
Weight: 113 g
VPN support: PPTP (client/server), L2TP over IPSec client/server, OpenVPN client/server, SSTP client/server, IPsec VPN (client/server)
Network
Policy-based routing: Yes
Ethernet LAN: Yes
Ethernet LAN interface type: Fast Ethernet
Dynamic DNS (DDNS): Yes
Port forwarding: Yes
Cabling technology: 10/100Base-T(X)
Number of guest networks (5 GHz): 7
Networking standards: IEEE 802.11r, IEEE 802.11v, IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11k
Number of guest networks (2.4 GHz): 7
Ethernet LAN data rates: 100, 10
Routing table: DHCP, Manual
VPN server: OpenVPN
IPoE/PPPoE data rate: 95 Mbit/s
Internet connection backup: Yes
L2TP/PPTP data rate: 95 Mbit/s
IntelliQoS: Yes
Ping check: Yes
WireGuard throughput: 45 Mbit/s
PPPoE/PPTP/L2TP pass-through: Yes
System requirements
Mobile operating systems supported: iOS, Android
Packaging data
Number of products included: 1 pc(s)
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
Quick installation guide: Yes
AC adapter included: Yes
Wireless LAN features
WLAN data transfer rate (first band): 300 Mbit/s
Wi-Fi band: Single-band (2.4 GHz)
WLAN data transfer rate (max): 300 Mbit/s
Wi-Fi standards: Wi-Fi 4 (802.11n)
Top Wi-Fi standard: Wi-Fi 4 (802.11n)
Protocols
Universal Plug and Play (UPnP): Yes
IPv4 & IPv6 features: Dual stack IPv4/IPv6, IPv6 SSH, IPv6 Telnet
Supported network protocols: IPoE, PPPoE, PPTP, L2TP, 802.1x
DHCP server: Yes
DHCP client: Yes
UDP-to-HTTP proxy: Yes
Ports & interfaces
USB port: No
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 3
Antenna
Antennas quantity: 2
Antenna design: External
WAN connection
WAN connection type: RJ-45, WISP
Ethernet WAN: Yes
Supported protocols: EoIP, IP-IP, GRE
Supported WAN type: Multi-WAN
Other features
Number of users: 75 user(s)
Mobile network
USSD request support: Yes
