Features
Processor frequency: 1800 MHz
Internal memory: 1024 MB
Internal memory type: DDR4
Processor cores: 3
Processor model: MediaTek MT7988D
Firmware upgradeable: Yes
Built-in processor: Yes
Processor manufacturer: MediaTek
Flash memory: 256 MB
WireGuard: Yes
Cloudflare DNS: Yes
AdGuard ad blocker: Yes
Design
LED indicators: LAN, Power, WLAN
Housing material: Plastic
Product type: Tabletop router
Product colour: White
Power
AC input frequency: 50/60 Hz
Output current: 3 A
AC input voltage: 100 - 240 V
Power source type: AC
Output voltage: 12 V
Security
System event log: Yes
Parental control: Yes
DoS attack prevention: Yes
IGMP snooping: Yes
Firewall: Yes
Guest access: Yes
Firewall security: SPI
Security algorithms: WPA2-PSK, OWE, WPA2-Enterprise, WPA3-PSK, WPA-PSK, WPA3-Enterprise, WEP
Network address translation (NAT): Yes
MAC address filtering: Yes
Schedule access: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 95%
Management features
Captive portal: Yes
Web-based setup wizard: Yes
Traffic statistics: Yes
Cloud-managed: Yes
WPS push button: Yes
MU-MIMO technology: Yes
Command-line interface (CLI): Yes
Intelligent Mesh technology: Yes
Backup function: Yes
Bandwidth control: Yes
Number of data streams: 4x4
Reset button: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
Web-based management: Yes
MIMO: Yes
Quality of Service (QoS) support: Yes
Direct or cloud access via KeenDNS: Yes
HTTPS security for access via KeenDNS: Yes
Weight & dimensions
Height: 45 mm
Width: 217 mm
Depth: 159 mm
Weight: 735 g
VPN support: PPTP (client/server), L2TP over IPSec client/server, OpenVPN client/server, SSTP client/server, IPsec VPN (client/server)
Network
Dynamic DNS (DDNS): Yes
Port forwarding: Yes
Policy-based routing: Yes
Built-in FTP server: Yes
Networking standards: IEEE 802.11a, IEEE 802.11r, IEEE 802.11be, IEEE 802.11v, IEEE 802.11k, IEEE 802.1Q, IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Support Samba (storage): Yes
Number of guest networks (5 GHz): 7
Media server: Yes
IPoE/PPPoE data rate: 10000 Mbit/s
Number of guest networks (2.4 GHz): 7
Ethernet LAN interface type: 10 Gigabit Ethernet
Ethernet LAN data rates: 2500, 100, 10, 10000 Mbit/s, 1000 Mbit/s
Ethernet LAN: Yes
VPN server: OpenVPN
L2TP/PPTP data rate: 3000 Mbit/s
PPPoE/PPTP/L2TP pass-through: Yes
Cabling technology: 10/100/1000/2500/5000/10000Base-T
Routing table: DHCP, Manual
Internet connection backup: Yes
WireGuard throughput: 900 Mbit/s
Ping check: Yes
IntelliQoS: Yes
System requirements
Mobile operating systems supported: iOS, Android
Packaging content
Quick start guide: Yes
Cables included: LAN (RJ-45)
AC adapter included: Yes
Wireless LAN features
WLAN data transfer rate (second band): 5764 Mbit/s
WLAN data transfer rate (first band): 300 Mbit/s
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN data transfer rate (max): 7200 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Modulation: OFDMA
Wi-Fi standards: Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Protocols
IPv4 & IPv6 features: Dual stack IPv4/IPv6, IPv6 Telnet, IPv6 SSH
Universal Plug and Play (UPnP): Yes
DHCP client: Yes
Supported network protocols: IPoE, PPPoE, PPTP, L2TP, 802.1x
DHCP server: Yes
UDP-to-HTTP proxy: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 6
DC-in jack: Yes
USB port: Yes
USB 2.0 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Antenna
Antenna design: External
Antennas quantity: 4
WAN connection
3G/4G USB modem compatibility: Yes
WAN connection type: RJ-45, WISP
DSL WAN: No
SIM card slot: No
Ethernet WAN: Yes
Supported WAN type: Multi-WAN
Supported protocols: EoIP, IP-IP, GRE
Other features
Number of users: 512 user(s)
Mobile network
USSD request support: Yes
