Technical details
Linear (1D) barcodes supported: Interleaved 2 of 5, Code 3 of 9, Code 128, UPC-E, EAN-13, EAN-8, UPC-A, Codabar, PDF417
Sustainability certificates: EPEAT Silver, ENERGY STAR
Design
Product colour: Black
Display diagonal: 24.6 cm (9.7")
Built-in display: Yes
Display: LCD
Touchscreen: Yes
Colour display: Yes
Scanner type: ADF + Sheet-fed scanner
Power
AC input frequency: 50 - 60 Hz
Input voltage: 100 - 240 V
Power consumption (standby): 0.3 W
Power supply type: AC
Power consumption (typical): 49 W
Power consumption (sleep): 5.26 W
Operational conditions
Operating temperature (T-T): 10 - 35 °C
Operating relative humidity (H-H): 10 - 85%
Weight & dimensions
Weight: 10.5 kg
Width: 356 mm
Height: 206 mm
Depth: 382 mm
Network
Ethernet LAN: Yes
Supported network protocols: SMTP, DHCP, FTP, HTTP, SMB, TCP/IP, WINS
System requirements
Windows operating systems supported: Windows 8.1 Enterprise, Windows 7 Professional, Windows 10 Home x64, Windows 8.1, Windows 8.1 Pro, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 7 Home Premium x64, Windows 10 Education, Windows 10 Pro x64, Windows 10 Enterprise x64, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 10, Windows 10 IOT Core, Windows 7 Professional x64, Windows 10 Home, Windows 7 Starter x64, Windows 10 IoT Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 7 Enterprise x64, Windows 7, Windows 10 Education x64, Windows 7 Home Basic, Windows 7 Enterprise, Windows 10 x64, Windows 7 Ultimate
Performance
Daily duty cycle (max): 6000 pages
Scan file formats: XLS, DOC, PDF, JPEG, TIFF
Scan drivers: WIA, TWAIN, ISIS, SANE, Kofax VRS
Light source: White LED
Scan to: USB, Fax, FTP, E-mail Server, E-mail
Sensor type: Dual CCD
Barcode reader: Yes
Recommended system requirements: INTEL CORE2 Duo 6600 2.4 GHz+, 4 GB RAM
Other features
Ethernet LAN data rates: 1000, 10, 100 Mbit/s
Minimum scan size: 50.8 x 63.5
Logistics data
Harmonized System (HS) code: 84716070
Input capacity
Auto document feeder (ADF) input capacity: 75 sheets
Paper handling
Auto Document Feeder (ADF) media weight: 34 - 200 g/m²
Card thickness (max): 1.2 mm
Scanning
ADF scan speed (b/w, A4): 70 ppm
Output greyscale depth: 8 bit
Colour scanning: Yes
Input colour depth: 48 bit
Optical scanning resolution: 600 x 600 DPI
Duplex scanning: Yes
Maximum scan size: 216 x 863 mm
Output colour depth: 24 bit
