Technical details
Maximum paper size: 216 x 3000 mm
Relative humidity: 15 - 80%
Scan technology: Dual CIS
Linear (1D) barcodes supported: Codabar, Code 3 of 9, Code 128, U.P.C., EAN-13, EAN-8, PDF417
PC connection: USB 3.2 Gen 1 (3.1 Gen 1)
Power: 36 W
Design
Display: LCD
Built-in display: Yes
Display diagonal: 8.89 cm (3.5")
Product colour: White, Black
Touchscreen: Yes
Scanner type: ADF scanner
Power
Input voltage: 100-240 V
AC input frequency: 50 - 60 Hz
Power consumption (PowerSave): 5 W
Power consumption (off): 5 W
Power supply: 36 W
Power consumption (standby): 3 W
Power supply type: AC
Power consumption (typical): 36 W
Operational conditions
Operating temperature (T-T): 10 - 35 °C, 50 - 95 °F
Operating relative humidity (H-H): 15 - 80%
Weight & dimensions
Weight: 7 kg
Width: 312 mm
Height: 182.5 mm
Depth: 269 mm
Network
Wi-Fi: Yes
Ethernet LAN: Yes
System requirements
Windows operating systems supported: Windows 7, Windows 10, Windows 8, Windows 8.1
Minimum RAM: 3430 MB
Minimum processor: INTEL CORE i3 - 4150 processor
Performance
Text-to-speech technology: No
Button functions: Cancel, Off, On
Built-in translator: No
Processor frequency: 1500 MHz
Scan drivers: ISIS, WIA, TWAIN
Scan file formats: BMP, PDF, CSV, TIFF, DOC, PNG, TXT, DOCS, XLS, XLSX
Scan to: OCR, TWAIN, E-mail Server, File, Cloud, WIA, PC, Image, E-mail
Built-in processor: Yes
Daily duty cycle (max): 8000 pages
Sensor type: Dual CIS
Barcode reader: Yes
Light source: RGB LED
Bundled software: WINDOWS Bundled software: TWAIN, ISIS, WIA Drivers; Capture Pro Limited Edition, Smart Touch, LINUX drivers available from www.kodak.com/go/scanonlinux (September Availability) KOFAX certified. (Future Availability)
Packaging content
ADF paper chute: Yes
Stacker: Yes
Cables included: AC, USB
Drivers included: Yes
Ports & interfaces
Standard interfaces: Ethernet, Wireless LAN, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1)
USB version: 3.2 Gen 2 (3.1 Gen 2)
USB port: Yes
Certification: EPEAT Registered
ENERGY STAR Qualified
AS/NZS CISPR 22:2009 +A1:2010; (Class B RCM mark), CAN / CSA – C22.2 No 60950-1-07 +A1:2011 (TUV C mark), Canada CSA-CISPR 22-10 / ICES-003 Issue 5 (Class B), China GB4943.1:2011; GB9254:2008 Class B (CCC S&E mark), EN55022:2010 ITE Emissions (Class B), EN55024:2010 ITE Immunity (CE mark), EN60950-1:2006 +A1,+A11,+A12 (TUV GS mark), IEC60950-1:2005 +A1, Taiwan CNS 13438:2006 (Class B); CNS 14336-1 (BSMI mark), UL 60950-1:2007 R12.11 (TUV US mark), CFR 47 Part 15 (FCC Class B), Argentina S markEPEAT Registered
ENERGY STAR Qualified
AS/NZS CISPR 22:2009 +A1:2010; (Class B RCM mark), CAN / CSA – C22.2 No 60950-1-07 +A1:2011 (TUV C mark), Canada CSA-CISPR 22-10 / ICES-003 Issue 5 (Class B), China GB4943.1:2011; GB9254:2008 Class B (CCC S&E mark), EN55022:2010 ITE Emissions (Class B), EN55024:2010 ITE Immunity (CE mark), EN60950-1:2006 +A1,+A11,+A12 (TUV GS mark), IEC60950-1:2005 +A1, Taiwan CNS 13438:2006 (Class B); CNS 14336-1 (BSMI mark), UL 60950-1:2007 R12.11 (TUV US mark), CFR 47 Part 15 (FCC Class B), Argentina S mark
Other features
Downloadable software: Capture Pro Limited Edition, Smart Touch
Selectable background colour: No
Logistics data
Harmonized System (HS) code: 84716070
Input capacity
Auto document feeder (ADF) input capacity: 80 sheets
Standard input capacity: 80 sheets
Paper handling
Auto Document Feeder (ADF) media weight: 27 - 413 g/m²
Legal: Yes
Maximum ISO A-series paper size: A4
Scanning media types supported: Thin paper, Plastic Card, Thick paper, Envelopes, Recycled paper, Business Card, Plain paper
ISO A-series sizes (A0...A9): A4
Minimum scan area (ADF): 52 x 52 mm
Maximum scan length: 3 m
Maximum scan area (ADF): 215 x 155.6 mm
Multi feed detection: Yes
Maximum scan width: 21.6 cm
Scanning
Scan speed (colour, high res, A4): 80 sec/page
Scan speed (b/w, low res, A4): 80 sec/page
Scan speed (colour, low res, A4): 80 sec/page
Scan speed (b/w, high res, A4): 80 sec/page
ADF scan speed (b/w, A4): 80 ppm
Optical scanning resolution: 600 x 600 DPI
Black/white scanning colour modes: Grayscale
Maximum scan size: 216 x 3000 mm
Output greyscale depth: 8 bit
Colour scanning: Yes
Duplex ADF scan speed (b/w, A4): 160 ipm
Greyscale levels: 256
Output colour depth: 24 bit
Film scanning: No
Duplex scanning: Yes
Input colour depth: 30 bit
ADF scan speed (colour, A4): 80 ppm
Duplex ADF scan speed (colour, A4): 160 ipm
Sustainability
Sustainability certificates: ENERGY STAR
