Design
Product colour: Black
On/off switch: Yes
Cooling type: Active
Fan diameter: 12 cm
Power
Power protection features: Short circuit, Under voltage, Over voltage, Overheating, Over power, Over current, Surge and inrush
Input current: 5.5 - 11 A
AC input voltage: 100 - 240 V
AC input frequency: 47 - 63 Hz
Hold time: 17 ms
Max output current (+12V): 62.5 A
Combined power (-12V): 3.6 W
Combined power (+5V): 130 W
Max output current (+3.3V): 20 A
Efficiency: 92%
Maximum input current (@110V): 5.5 A
Combined power (+12V): 750 W
Combined power (+3.3V): 130 W
Power Factor Correction (PFC) type: Active
Max output current (+5Vsb): 3 A
Total power: 700 W
Maximum input current (@220V): 11 A
Combined power (+5Vsb): 15 W
Max output current (-12V): 0.3 A
Max output current (+5V): 20 A
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Height: 86 mm
Depth: 150 mm
Width: 140 mm
Performance
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Purpose: PC
Bearing technology: FDB
ATX version: 3.0
Mean time between failures (MTBF): 15000 h
Packaging data
Package depth: 210 mm
Package height: 110 mm
Package width: 295 mm
Package weight: 2.47 kg
Package type: Box
Packaging content
Cables included: CPU, PATA, SATA
Ports & interfaces
Number of SATA power cables: 2
Peripheral (Molex) power connectors (4-pin): 4
SATA power cable length: 500 mm, 800 mm, 650
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 60 cm
ATX power connector (20+4 pin): Yes
Number of SATA power connectors: 3
EPS power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 2
CPU power connector (4+4 pin): Yes
Peripheral (Molex) power cable length: 500 mm, 800, 950 mm, 650
Cabling type: Fully-Modular
Number of PATA power connectors: 4
CPU power cable length: 65 cm
Safety warning
Warnings: Avoid contact of the product with water or other liquids., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Do not open the case - risk of electric shock.
