Technical details
Compliance certificates: REACH, RoHS
Replacement cartridges: TK-8115K, TK-8115C, TK-8115M, TK-8115Y
Features
Printer fonts: Windows, Barcode, PCL, Bitmap
Duplex functions: Copy, Print, Scan
Number of printer fonts: 101
Printing colours: Black, Cyan, Magenta, Yellow
Recommended duty cycle: 2000 - 5000 pages per month
Maximum duty cycle: 100000 pages per month
Optional functions: Fax
Number of print cartridges: 4
Page description languages: PostScript 3, PCL 6, PCL 5e, Microsoft XPS, OpenXPS, PCL XL
Design
Built-in display: Yes
Display: TFT
Display diagonal: 10.9 cm (4.3")
Touchscreen: Yes
Product colour: Black
Colour display: Yes
Control type: Touch
Power
Power consumption (max): 1575 W
Power consumption (off): 0.1 W
AC input voltage: 220 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (PowerSave): 40 W
Power consumption (ready): 80 W
Power consumption (sleep): 0.5 W
Power consumption (copying): 510 W
Power consumption (printing): 510 W
Power consumption (average operating): 510 W
Operational conditions
Storage temperature (T-T): -20 - 40 °C
Operating relative humidity (H-H): 10 - 80%
Operating temperature (T-T): 10 - 32.5 °C
Weight & dimensions
Width: 590 mm
Depth: 590 mm
Weight: 76 kg
Height: 753 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Wi-Fi: No
Ethernet LAN: Yes
Bluetooth: No
Cabling technology: 10/100/1000Base-T(X)
Email protocols: POP3, SMTP
Mobile printing technologies: Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Email over SSL: Yes
Near Field Communication (NFC): No
System requirements
Mac operating systems supported: Mac OS X 10.14 Mojave, Mac OS X 10.5 Leopard, Mac OS X 10.13 High Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.15 Catalina
Windows operating systems supported: Yes
Linux operating systems supported: Yes
Performance
Processor frequency: 1200 MHz
Compatible memory cards: SD
Processor family: ARM Cortex-A9
Card reader integrated: Yes
Processor cores: 2
Maximum internal memory: 3000 MB
Sound pressure level (printing): 53 dB
Internal memory: 1500 MB
Sound pressure level (copying): 53 dB
Sound pressure level (standby): 34 dB
Built-in processor: Yes
Packaging data
Package weight: 104 kg
Package width: 760 mm
Package depth: 760 mm
Package height: 995 mm
Packaging content
Quick installation guide: Yes
Drivers included: Yes
Manual: Yes
Cables included: AC
Power cord included: Yes
Included cartridge capacity (CMY): 1500 pages
Cartridge(s) included: Yes
Included cartridge capacity (black): 3000 pages
Imaging unit included: Yes
Certification: TÜV/GS, CE
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Ports & interfaces
USB 2.0 ports quantity: 3
Standard interfaces: Ethernet, USB 2.0
Direct printing: Yes
Optional connectivity: Ethernet, Wireless LAN
USB port: Yes
Other features
Finishing option: No
Printing
Print technology: Laser
Warm-up time: 30 s
Poster printing function: Yes
N-up printing: 4, 2
Print resolution colour: 1200 x 1200 DPI
Maximum resolution: 9600 x 600 DPI
Secure printing: Yes
Duplex print speed (black, normal quality, A4/US Letter): 22 ppm
Print resolution black: 1200 x 1200 DPI
Duplex printing: Yes
Duplex printing mode: Auto
Duplex print speed (colour, normal quality, A4/US Letter): 22 ppm
Print speed (colour, normal quality, A3): 12 ppm
Secure PDF printing function: Yes
Printing: Colour printing
Print speed (black, normal quality, A4/US Letter): 24 ppm
Watermark printing: Yes
Print speed (black, normal quality, A3): 12 ppm
Barcode printing: Yes
Time to first page (colour, normal): 10.2 s
Print speed (colour, normal quality, A4/US Letter): 24 ppm
N-in-1 print function: Yes
Time to first page (black, normal): 7.5 s
Economical printing: Yes
Copying
N-in-1 copy function (N=): 2, 4
Copier resize: 25 - 400%
N-in-1 copy function: Yes
Maximum number of copies: 999 copies
Duplex copying: Yes
Copying: Colour copying
Copy speed (colour, normal quality, A3): 12 cpm
Time to first copy (black, normal): 7.6 s
Duplex copying mode: Auto
Maximum copy resolution: 600 x 600 DPI
Time to first copy (colour, normal): 9.8 s
Copy speed (colour, normal quality, A4): 24 cpm
ID-card copy function: Yes
Copy speed (black, normal quality, A4): 24 cpm
Copy speed (black, normal quality, A3): 12 cpm
Duplex copy speed (black, US Letter): 22 ppm
Copy programming function: Yes
Logistics data
Harmonized System (HS) code: 84433100
Fax
Fax coding methods: JBIG, MH, MR, MMR
Modem speed: 33.6 Kbit/s
Duplex faxing: Yes
Faxing: No
Fax transmission speed: 3 sec/page
Fax resolution (black): 400 x 400 DPI
Input & output capacity
Total input capacity: 500 sheets
Auto document feeder (ADF): Yes
Total output capacity: 280 sheets
Paper input type: Paper tray, Cassette
Maximum input capacity: 1600 sheets
Auto document feeder (ADF) input capacity: 50 sheets
Multi-Purpose tray: Yes
Paper tray 3 input capacity: 500 sheets
Maximum output capacity: 280 sheets
Multi-Purpose tray input capacity: 100 sheets
Paper tray 2 input capacity: 500 sheets
Maximum number of input trays: 3
Total number of input trays: 1
Paper tray 1 input capacity: 500 sheets
Paper handling
Maximum print size: 297 x 432 mm
Custom media width: 98 - 297 mm
Maximum ISO A-series paper size: A3
ISO A-series sizes (A0...A9): A3, A6, A5, A4
ISO B-series sizes (B0...B9): B5
Media thickness (min): 0.11 mm
Multi-Purpose Tray media weight: 60 - 256 g/m²
Multi-purpose tray media types: Legal, Letter
Paper tray media weight: 60 - 256 g/m²
Non-ISO print media sizes: Folio, Ledger (media size), Letter, Legal
Paper tray media types: Plain paper
Duplex media weight: 60 - 220 g/m²
Custom media length: 148 - 432 mm
Scanning
Maximum scan area: 297 x 420 mm
Scan to: FTP, USB, TWAIN, SMB, WIA, E-mail
Scan drivers: WIA, TWAIN
Optical scanning resolution: 600 x 600 DPI
Image formats supported: TIFF, JPEG, MMR
Document formats supported: XPS, PDF
Scan technology: CIS/CCD
Scan speed (colour): 50 ppm
Scanning: Colour scanning
Greyscale levels: 256
Duplex scanning mode: Auto
Scanner type: Flatbed & ADF scanner
Duplex scan speed (colour): 16 ppm
Duplex scan speed (black): 16 ppm
Duplex scanning: Yes
Scan speed (black): 50 ppm
Safety warning
Warnings: Follow local regulations for the disposal of electronic multifunctional devices., Do not dispose of used appliances and toner cartridges in the regular rubbish bin, they may contain substances harmful to the environment.
