Technical details
Compliance certificates: REACH, RoHS, WEEE
Replacement cartridges: TK-3300
Features
Maximum duty cycle: 150000 pages per month
Number of print cartridges: 1
All-In-One-multitasking: Yes
Country of origin: Vietnam
Duplex functions: Print, Scan, Copy
Recommended duty cycle: 3000 - 15000 pages per month
Digital sender: Yes
Page description languages: PCL 5e, PDF 1.4, PCL XL, PCL 6
Printing colours: Black
Printer fonts: PCL, Barcode, Bitmap
Design
Market positioning: Business
Control type: Touch
Colour display: Yes
Display diagonal: 17.8 cm (7")
Built-in display: Yes
Product colour: Black
Display: LCD
Power
AC input frequency: 50 - 60 Hz
Power consumption (off): 0.1 W
Power consumption (printing): 592 W
Energy Star Typical Electricity Consumption (TEC): 0.62 kWh/week
Power consumption (copying): 600 W
Power consumption (max): 1234 W
Power consumption (standby): 35 W
AC input voltage: 220 - 240 V
Power consumption (ready): 57.2 W
Power consumption (sleep): 0.5 W
Operational conditions
Operating relative humidity (H-H): 15 - 80%
Operating temperature (T-T): 10 - 32.5 °C
Storage temperature (T-T): -20 - 40 °C
Storage relative humidity (H-H): 10 - 90%
Operating altitude: 0 - 3500 m
Weight & dimensions
Width: 475 mm
Height: 575 mm
Weight: 23 kg
Depth: 476 mm
Network
Mobile printing technologies: Mopria Print Service, Kyocera Mobile Print, Apple AirPrint
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Wi-Fi: No
System requirements
Windows operating systems supported: Yes
Mac operating systems supported: Mac OS X 13.0 Ventura, Mac OS X 10.9 Mavericks, Mac OS X 12.0 Monterey, Mac OS X 11.0 Big Sur
Linux operating systems supported: Yes
Performance
Compatible memory cards: SD
Processor family: ARM Cortex-A5
Processor cores: 2
Internal memory: 1500 MB
Memory slots: 1
Card reader integrated: No
Sound pressure level (printing): 54 dB
Maximum internal memory: 3500 MB
Processor frequency: 1400 MHz
Sound pressure level (duplex printing): 54 dB
Built-in processor: Yes
Sound pressure level (copying): 54 dB
Introduction year: 2023
Sound pressure level (standby): 30 dB
Packaging data
Package depth: 570 mm
Package weight: 30 kg
Package height: 695 mm
Package width: 607 mm
Packaging content
Cables included: AC
Cartridge(s) included: Yes
Included cartridge capacity (black): 6000 pages
Imaging unit included: Yes
Ports & interfaces
Optional connectivity: Wireless LAN, Ethernet
USB port: Yes
Direct printing: Yes
USB 2.0 ports quantity: 1
Printing
Maximum resolution: 1200 x 1200 DPI
Watermark printing: Yes
Duplex printing: Yes
Economical printing: Yes
Print technology: Laser
N-in-1 print function: Yes
Print speed (black, normal quality, A4/US Letter): 45 ppm
Time to first page (black, normal): 5.3 s
N-up printing: 2, 6, 8, 16, 25, 4, 9
Poster printing function: Yes
Warm-up time: 23 s
Duplex printing mode: Auto
Secure printing: Yes
Printing: Mono printing
Duplex print speed (black, normal quality, A4/US Letter): 22.5 ppm
Cover page printing function: Yes
Copying
N-in-1 copy function (N=): 4, 2
Copier resize: 25 - 400%
Copy speed (black, normal quality, A4): 45 cpm
Copying: Mono copying
Maximum copy resolution: 600 x 600 DPI
ID-card copy function: Yes
N-in-1 copy function: Yes
Maximum number of copies: 999 copies
Time to first copy (black, normal): 6 s
Copy programming function: Yes
Duplex copying mode: Auto
Duplex copying: Yes
Background adjustment function: Yes
Maximum copy size: A4
Fax
Faxing: No
Input & output capacity
Maximum input capacity: 2600 sheets
Multi-Purpose tray input capacity: 100 sheets
Total number of input trays: 2
Auto document feeder (ADF): Yes
Auto document feeder (ADF) input capacity: 75 sheets
Total input capacity: 600 sheets
Total output capacity: 250 sheets
Maximum number of input trays: 6
Multi-Purpose tray: Yes
Maximum output capacity: 250 sheets
Paper tray 1 input capacity: 500 sheets
Paper handling
Non-ISO print media sizes: Legal, Folio, Letter
Custom media length: 210 - 356 mm
Custom media width: 140 - 216 mm
ISO B-series sizes (B0...B9): B6, B5
ISO A-series sizes (A0...A9): A6, A4, A5
Paper tray media types: Labels, Banner, Thicker paper, Thin paper, Plain paper, Letterhead, Pre-printed, Thick paper
Maximum ISO A-series paper size: A4
Multi-Purpose Tray media weight: 60 - 220 g/m²
Paper tray media weight: 60 - 120 g/m²
Maximum print size: 216 x 356 mm
Scanning
Maximum scan area: 210 x 297 mm
Greyscale levels: 256
Scan to: FTP, File, Print, Image, PC, USB, TWAIN, SMB, WIA, E-mail
Scan speed (colour): 40 ppm
Scan speed (black): 60 ppm
Scan drivers: TWAIN, WIA
Optical scanning resolution: 600 x 600 DPI
Duplex scanning: Yes
Scan technology: CIS/CCD
Optical scanning resolution (colour): 300 x 300 ppi
Scanner type: Flatbed & ADF scanner
Scanning: Colour scanning
Image formats supported: TIFF, JPEG
Optical scanning resolution (black): 600 x 600 ppi
Duplex scan speed (colour): 17 ppm
Document formats supported: XPS, PDF
Duplex scanning mode: Auto
Maximum scan resolution: 600 x 600 DPI
Duplex scan speed (black): 26 ppm
Optical scanning resolution (ADF): 600 x 600 DPI
Sustainability
Sustainability compliance: Yes
Sustainability certificates: Turkish Environment Label, Blue Angel, EPEAT Gold
