Technical details
Compliance certificates: RoHS, REACH, WEEE
Replacement cartridges: TK-3300
Features
Number of print cartridges: 1
Maximum duty cycle: 150000 pages per month
All-In-One-multitasking: Yes
Printing colours: Black
Digital sender: Yes
Duplex functions: Print, Scan, Copy
Recommended duty cycle: 3000 - 15000 pages per month
Printer fonts: Barcode, Bitmap, PCL
Page description languages: PCL XL, PCL 6, PDF 1.4, PCL 5e
Design
Colour display: Yes
Control type: Touch
Display: LCD
Product colour: Black
Display diagonal: 17.8 cm (7")
Built-in display: Yes
Power
Power consumption (copying): 600 W
Power consumption (printing): 592 W
Power consumption (sleep): 0.5 W
Power consumption (ready): 57.2 W
Power consumption (standby): 35 W
AC input frequency: 50 - 60 Hz
Power consumption (off): 0.1 W
AC input voltage: 220 - 240 V
Power consumption (max): 1234 W
Operational conditions
Operating relative humidity (H-H): 15 - 80%
Operating temperature (T-T): 10 - 32.5 °C
Storage temperature (T-T): -20 - 40 °C
Weight & dimensions
Weight: 23 kg
Height: 575 mm
Width: 475 mm
Depth: 476 mm
Network
Mobile printing technologies: Mopria Print Service, Apple AirPrint, Kyocera Mobile Print
Ethernet LAN data rates: 10,100,1000 Mbit/s
Wi-Fi: No
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
System requirements
Linux operating systems supported: Yes
Mac operating systems supported: Mac OS X 12.0 Monterey, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura, Mac OS X 10.9 Mavericks
Windows operating systems supported: Yes
Performance
Memory slots: 1
Sound pressure level (duplex printing): 54 dB
Introduction year: 2023
Internal memory: 1500 MB
Maximum internal memory: 3500 MB
Built-in processor: Yes
Sound pressure level (standby): 30 dB
Sound pressure level (copying): 54 dB
Sound pressure level (printing): 54 dB
Processor cores: 2
Processor family: ARM Cortex-A5
Processor frequency: 1400 MHz
Compatible memory cards: SD
Card reader integrated: No
Packaging data
Package depth: 570 mm
Package width: 607 mm
Package weight: 30 kg
Package height: 695 mm
Packaging content
Imaging unit included: Yes
Included cartridge capacity (black): 6000 pages
Cartridge(s) included: Yes
Cables included: AC
Ports & interfaces
Direct printing: Yes
USB port: Yes
Optional connectivity: Wireless LAN, Ethernet
USB 2.0 ports quantity: 1
Printing
N-up printing: 8, 16, 4, 2, 6, 9, 25
Print technology: Laser
Time to first page (black, normal): 5.3 s
Economical printing: Yes
N-in-1 print function: Yes
Duplex printing: Yes
Cover page printing function: Yes
Secure printing: Yes
Printing: Mono printing
Maximum resolution: 1200 x 1200 DPI
Poster printing function: Yes
Print speed (black, normal quality, A4/US Letter): 45 ppm
Warm-up time: 23 s
Watermark printing: Yes
Duplex printing mode: Auto
Duplex print speed (black, normal quality, A4/US Letter): 22.5 ppm
Copying
Maximum copy size: A4
Maximum copy resolution: 600 x 600 DPI
ID-card copy function: Yes
Maximum number of copies: 999 copies
N-in-1 copy function (N=): 2, 4
Copy programming function: Yes
Duplex copying mode: Auto
Time to first copy (black, normal): 6 s
Copy speed (black, normal quality, A4): 45 cpm
Copying: Mono copying
Copier resize: 25 - 400%
Background adjustment function: Yes
Duplex copying: Yes
N-in-1 copy function: Yes
Fax
Faxing: No
Input & output capacity
Auto document feeder (ADF) input capacity: 75 sheets
Multi-Purpose tray input capacity: 100 sheets
Paper tray 1 input capacity: 500 sheets
Total number of input trays: 2
Multi-Purpose tray: Yes
Maximum input capacity: 2600 sheets
Auto document feeder (ADF): Yes
Maximum output capacity: 250 sheets
Total output capacity: 250 sheets
Total input capacity: 600 sheets
Maximum number of input trays: 6
Paper handling
Maximum print size: 216 x 356 mm
Custom media width: 140 - 216 mm
Non-ISO print media sizes: Letter, Folio, Legal
Maximum ISO A-series paper size: A4
ISO A-series sizes (A0...A9): A5, A4, A6
ISO B-series sizes (B0...B9): B5, B6
Custom media length: 210 - 356 mm
Multi-Purpose Tray media weight: 60 - 220 g/m²
Paper tray media types: Thin paper, Labels, Banner, Thicker paper, Plain paper, Pre-printed, Thick paper, Letterhead
Paper tray media weight: 60 - 120 g/m²
Scanning
Scan to: SMB, WIA, USB, TWAIN, File, Print, PC, FTP, E-mail, Image
Scan technology: CIS/CCD
Scanning: Colour scanning
Image formats supported: JPEG, TIFF
Optical scanning resolution (black): 600 x 600 ppi
Document formats supported: XPS, PDF
Scanner type: Flatbed & ADF scanner
Scan drivers: TWAIN, WIA
Greyscale levels: 256
Maximum scan area: 210 x 297 mm
Scan speed (colour): 40 ppm
Duplex scanning mode: Auto
Maximum scan resolution: 600 x 600 DPI
Optical scanning resolution: 600 x 600 DPI
Duplex scanning: Yes
Scan speed (black): 60 ppm
Optical scanning resolution (ADF): 600 x 600 DPI
Optical scanning resolution (colour): 300 x 300 ppi
Duplex scan speed (colour): 17 ppm
Duplex scan speed (black): 26 ppm
Safety warning
Warnings: Avoid contact with toner, it can irritate the skin and respiratory tract., The product requires special disposal - do not dispose of in normal waste., Be careful when handling the device, it may contain live parts.
Sustainability
Sustainability compliance: Yes
