Technical details
Compliance certificates: RoHS, REACH
Replacement cartridges: TK-3400
Features
Page description languages: PCL XL, PCL 6, PDF 1.4, PCL 5e
Printer fonts: PCL, Barcode, Bitmap
Duplex functions: Print, Copy, Scan
Printing colours: Black
Digital sender: Yes
Recommended duty cycle: 3000 - 15000 pages per month
Number of print cartridges: 1
Maximum duty cycle: 150000 pages per month
All-In-One-multitasking: Yes
Design
Built-in display: Yes
Display: LCD
Product colour: Black
Colour display: No
Control type: Buttons
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 220 - 240 V
Power consumption (max): 1234 W
Power consumption (off): 0.1 W
Power consumption (copying): 585 W
Power consumption (printing): 602 W
Power consumption (ready): 55 W
Power consumption (sleep): 0.5 W
Power consumption (standby): 38 W
Operational conditions
Operating relative humidity (H-H): 15 - 80%
Operating temperature (T-T): 10 - 32.5 °C
Storage temperature (T-T): -20 - 40 °C
Weight & dimensions
Weight: 22.8 kg
Depth: 476 mm
Height: 575 mm
Width: 475 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Wi-Fi: No
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Mobile printing technologies: Apple AirPrint, Mopria Print Service, Kyocera Mobile Print
System requirements
Mac operating systems supported: Mac OS X 12.0 Monterey, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura
Windows operating systems supported: Yes
Linux operating systems supported: Yes
Performance
Processor frequency: 1400 MHz
Processor family: ARM Cortex-A5
Introduction year: 2023
Compatible memory cards: SD
Processor cores: 2
Card reader integrated: No
Sound pressure level (standby): 30 dB
Sound pressure level (printing): 54 dB
Sound pressure level (copying): 54 dB
Internal memory: 1000 MB
Maximum internal memory: 3000 MB
Built-in processor: Yes
Memory slots: 1
Packaging data
Package width: 607 mm
Package weight: 30 kg
Package height: 695 mm
Package depth: 570 mm
Packaging content
Cables included: AC
Cartridge(s) included: Yes
Imaging unit included: Yes
Included cartridge capacity (black): 6000 pages
Ports & interfaces
USB 2.0 ports quantity: 1
Direct printing: Yes
Optional connectivity: Ethernet, Wireless LAN
USB port: Yes
Printing
Print technology: Laser
N-up printing: 9, 25, 4, 8, 6, 16, 2
Duplex print speed (black, normal quality, A4/US Letter): 22.5 ppm
Secure printing: Yes
Watermark printing: Yes
Warm-up time: 16 s
N-in-1 print function: Yes
Poster printing function: Yes
Cover page printing function: Yes
Print speed (black, normal quality, A4/US Letter): 45 ppm
Duplex printing mode: Auto
Printing: Mono printing
Maximum resolution: 1200 x 1200 DPI
Duplex printing: Yes
Economical printing: Yes
Time to first page (black, normal): 5.3 s
Copying
N-in-1 copy function (N=): 4, 2
Maximum copy size: A4
Copier resize: 25 - 400%
ID-card copy function: Yes
Copy programming function: Yes
Background adjustment function: Yes
N-in-1 copy function: Yes
Duplex copying: Yes
Duplex copying mode: Auto
Copy speed (black, normal quality, A4): 45 cpm
Maximum copy resolution: 600 x 600 DPI
Maximum number of copies: 999 copies
Copying: Mono copying
Time to first copy (black, normal): 6 s
Fax
Faxing: No
Input & output capacity
Multi-Purpose tray: Yes
Total number of input trays: 2
Total output capacity: 250 sheets
Auto document feeder (ADF): Yes
Total input capacity: 600 sheets
Paper tray 1 input capacity: 500 sheets
Maximum number of input trays: 6
Auto document feeder (ADF) input capacity: 75 sheets
Maximum input capacity: 2600 sheets
Multi-Purpose tray input capacity: 100 sheets
Maximum output capacity: 250 sheets
Paper handling
Custom media length: 210 - 356 mm
Custom media width: 140 - 216 mm
Maximum print size: 216 x 356 mm
Paper tray media types: Pre-printed, Thicker paper, Plain paper, Letterhead, Banner
Multi-Purpose Tray media weight: 60 - 220 g/m²
Paper tray media weight: 60 - 120 g/m²
Non-ISO print media sizes: Folio, Letter, Legal
ISO A-series sizes (A0...A9): A4, A6, A5
ISO B-series sizes (B0...B9): B6, B5
Maximum ISO A-series paper size: A4
Scanning
Optical scanning resolution (ADF): 600 x 600 DPI
Duplex scan speed (black): 26 ppm
Optical scanning resolution (colour): 300 x 300 ppi
Duplex scan speed (colour): 17 ppm
Optical scanning resolution (black): 600 x 600 ppi
Duplex scanning mode: Auto
Greyscale levels: 256
Scanning: Colour scanning
Scan to: E-mail, Image, Fax, USB, TWAIN, PC, File, Memory card, SMB, WIA, FTP
Scan technology: CIS/CCD
Scanner type: Flatbed & ADF scanner
Image formats supported: TIFF, JPEG
Document formats supported: PDF, XPS
Maximum scan resolution: 600 x 600 DPI
Optical scanning resolution: 600 x 600 DPI
Maximum scan area: 210 x 297 mm
Scan speed (black): 60 ppm
Scan speed (colour): 40 ppm
Duplex scanning: Yes
Scan drivers: TWAIN, WIA
Sustainability
Sustainability compliance: Yes
