Design
Antenna direction type: Omni-directional
Antenna: No
Internal: No
Antenna design: External
Antenna gain level (max): 5 dBi
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Height: 10 mm
Depth: 18.3 mm
Width: 47.7 mm
Weight: 22.6 g
Network
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11b
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Security algorithms: 64-bit WEP, WPS, 128-bit WEP, WPA-PSK, WPA3, WPA2-PSK
Networking standards: IEEE 802.11b, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate: 600 Mbit/s
Modulation: CCK, OFDM, DQPSK, DBPSK
System requirements
Linux operating systems supported: Yes
Windows operating systems supported: Windows 10, Windows 11
Ports & interfaces
Interface: WLAN
Host interface: USB
USB version: 2.0
Connectivity technology: Wireless
