Design
Internal: Yes
Product colour: Black
Antenna type: 2x2
Antenna design: External
Component for: PC
Antenna gain level (max): 5 dBi
Antenna: Yes
Chipset: RTL8812BU
Power
USB powered: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Weight: 24 g
Width: 20.5 mm
Height: 10.3 mm
Depth: 46.2 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Modulation: DQPSK, 256-QAM, 64-QAM, DSSS, DBPSK, OFDM, CCK, QPSK, 16-QAM, BPSK
LAN controller: Realtek RTL8812BU
Networking standards: IEEE 802.11a, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11e, IEEE 802.11n, IEEE 802.11i
Security algorithms: WMM, 128-bit WEP, WPA-PSK, WPA2-PSK, 64-bit WEP, WPA2, WPA, WPS-PIN, WEP, WPS-PBC, WPS
Frequency range: 2.4 - 5 GHz
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Wi-Fi: Yes
Maximum data transfer rate: 1200 Mbit/s
System requirements
Windows operating systems supported: Windows 8 x64, Windows XP, Windows 10, Windows 10 x64, Windows 8, Windows 7, Windows Vista x64, Windows 11, Windows Vista, Windows 7 x64
Linux operating systems supported: Yes
Mac operating systems supported: Yes
Ports & interfaces
Host interface: USB
USB version: 3.2 Gen 1 (3.1 Gen 1)
Connectivity technology: Wireless
Interface: WLAN
USB connector form factor: Straight
