Features
Antenna type: External
Antennas quantity: 2
Antenna connector type: SMA
Antenna gain level (max): 2 dBi
Design
Number of fans: 1 fan(s)
Cable lock slot type: Kensington
Product colour: Black
Power
Heat dissipation: 68 BTU/h
Power consumption (max): 17 W
Power consumption (idle): 6 W
Security
Security algorithms: SHA-384, SHA-512, 2048-bit RSA, 1024-bit RSA, FIPS 140, AES, SHA-256, 256-bit AES-CBC, SHA-1, 4096-bit RSA, 3DES, MD5
Network address translation (NAT): Yes
VLAN support: Yes
Access Control List (ACL): Yes
Password protection: Yes
Number of VLANs: 4096
Firewall security: Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Management features
Reset button: Yes
IGMP snooping: Yes
DHCPv6 snooping: Yes
Multicast Listener Discovery (MLD) snooping: Y
Traffic shaping: Yes
Weight & dimensions
Width: 210 mm
Weight: 450 g
Depth: 140 mm
Height: 45 mm
Network
Ethernet LAN data rates: 1000, 100, 10
UMTS bands supported: 900, 850, 2100 MHz, 1800
Data network: LTE, HSPA, UMTS
Networking standards: IEEE 802.1Q, IEEE 802.3az
PPTP/L2TP VPN tunnels (max): 5
Dynamic DNS (DDNS): Yes
4G bands supported: 2100, 800, 700, 2300, 900, 2600 MHz, 850, 2500, 1500, 1800
Mobile network generation: 4G
Performance
Control display unit: No
Packaging data
Package width: 210 mm
Package height: 110 mm
Package depth: 320 mm
Packaging content
Quick installation guide: Yes
Cables included: LAN (RJ-45)
AC adapter included: Yes
Certificates
Compliance certificates: CE
Protocols
Routing protocols: BGP4, RIP-2, OSPFv2, VRRP, LISP
DMZ support: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 4
Serial interface type: USB C
Combo SFP ports quantity: 1
USB 2.0 ports quantity: 1
DC-in jack: Yes
SIM card slot: Yes
WAN connection: Ethernet (RJ-45), SFP
SIM card type: MicroSIM
Antenna
Transmitting power (FCC): 23 dBm
Transmitting power (CE): 23 dBm
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
