Features
Antenna connector type: SMA
Antenna type: External
Antennas quantity: 4
Antenna gain level (max): 2 dBi
Design
Product colour: Black
Cable lock slot type: Kensington
Number of fans: 1 fan(s)
Power
Heat dissipation: 72 BTU/h
Power consumption (max): 18 W
Power consumption (idle): 6 W
Security
Security algorithms: FIPS 140, 3DES, AES, 4096-bit RSA, SHA-256, 1024-bit RSA, SHA-384, SHA-512, 2048-bit RSA, SHA-1
MAC address filtering: Yes
Number of VLANs: 4096
VLAN support: Yes
Access Control List (ACL): Yes
Firewall security: Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Password protection: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Reset button: Yes
DHCPv6 snooping: Yes
Syslog: Yes
Multicast support: Yes
IGMP snooping: Yes
Traffic shaping: Yes
Multicast Listener Discovery (MLD) snooping: Y
Weight & dimensions
Weight: 450 g
Depth: 140 mm
Height: 45 mm
Width: 210 mm
Network
Networking standards: IEEE 802.1Q, IEEE 802.3az
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
UMTS bands supported: 1800, 850, 1900, 2600 MHz, 900, 2100 MHz, 1700, 800
4G standard: LTE
4G bands supported: 900, 700, 1800, 2600 MHz, 850, 1900, 1500, 3700 MHz, 2000, 3500, 2100, 800, 1700, 5200 MHz, 2300
3G standards: HSPA, UMTS
Load balancing: Yes
Mobile network generation: 5G
Dynamic DNS (DDNS): Yes
Performance
Control display unit: No
Packaging data
Package weight: 1.66 kg
Package height: 94 mm
Package width: 385 mm
Package depth: 288 mm
Packaging content
Cables included: LAN (RJ-45)
Quick installation guide: Yes
AC adapter included: Yes
Certificates
Compliance certificates: PTCRB, RCM, CE, Federal Communications Commission (FCC)
Protocols
Routing protocols: OSPFv2, VRRP, BGP4, LISP, RIP-2
Ports & interfaces
WAN connection: Ethernet (RJ-45)
Fixed SFP ports quantity: 1
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 4
Serial interface type: USB C
USB 2.0 ports quantity: 1
SIM card slot: Yes
SIM card type: MicroSIM
Antenna
Transmitting power (CE): 23 dBm
Transmitting power (FCC): 23 dBm
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
Safety warning
Warnings: Avoid contact with liquids as this may cause electric shock., Dispose of in accordance with local regulations for electro-waste and batteries., Avoid contact with water and moisture to prevent short circuits., The product may emit radio waves that may interfere with other electronic devices., Do not open the appliance housing - risk of electric shock., Do not open the appliance - risk of electric shock.
Sustainability
Sustainability compliance: Yes
