Features
Antennas quantity: 2
Antenna connector type: SMA
Antenna type: External
Design
Number of fans: 1 fan(s)
LED indicators: Yes
Product colour: Black
Power
Power consumption (typical): 13 W
Power consumption (max): 27 W
Heat dissipation: 104 BTU/h
Security
Network address translation (NAT): Yes
Security algorithms: WPA3, AES-GCMP, EAP-TTLS, WPA2, WPA2-Enterprise, AES-CCMP, 4096-bit RSA, EAP-MD5, FIPS 140, 1024-bit RSA, EAP-FAST, WPA3-Enterprise, WEP, 802.1x RADIUS, MSCHAPv2, TKIP, 2048-bit RSA, EAP-TLS, EAP-GTC, PEAP
Password protection: Yes
VLAN support: Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Firewall security: Yes
Access Control List (ACL): Yes
MAC address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Management features
Quality of Service (QoS) support: Yes
DHCPv6 snooping: Yes
Reset button: Yes
Syslog: Yes
Multicast support: Yes
IGMP snooping: Yes
Traffic shaping: Yes
Multicast Listener Discovery (MLD) snooping: Y
Weight & dimensions
Depth: 190 mm
Width: 293 mm
Weight: 740 g
Height: 44 mm
Network
Networking standards: IEEE 802.3q
Modulation: 1024-QAM, 256-QAM
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Wi-Fi: No
PPTP/L2TP VPN tunnels (max): 25
Data network: 3G, HSPA, 4G, UMTS
Dynamic DNS (DDNS): Yes
Load balancing: Yes
Mobile network generation: 4G
Performance
Control display unit: No
Packaging data
Package height: 110 mm
Package width: 210 mm
Package depth: 320 mm
Package weight: 2.03 kg
Packaging content
Quick start guide: Yes
AC adapter included: Yes
Cables included: LAN (RJ-45)
Protocols
DHCP client: Yes
DHCP server: Yes
Routing protocols: BGP4, OSPFv2, LISP, RIP-2, VRRP
DMZ support: Yes
VoIP protocols: SIP ALG
Management protocols: SNMPv1,v2c,v3
Ports & interfaces
Ethernet LAN (RJ-45) ports: 5
DC-in jack: Yes
USB 2.0 ports quantity: 1
WAN connection: Ethernet (RJ-45)
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Germany
Sustainability
Sustainability compliance: Yes
