Features
Antennas quantity: 4
Antenna type: External
Antenna connector type: SMA
Design
Number of fans: 1 fan(s)
LED indicators: Yes
Product colour: Black
Power
Power consumption (max): 33 W
Power consumption (typical): 13 W
Heat dissipation: 132 BTU/h
Security
VLAN support: Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Firewall security: Yes
Access Control List (ACL): Yes
Password protection: Yes
Security algorithms: EAP-MD5, FIPS 140, 1024-bit RSA, TKIP, 2048-bit RSA, EAP-TLS, EAP-GTC, WPA2, WPA2-Enterprise, AES-CCMP, 4096-bit RSA, WEP, 802.1x RADIUS, MSCHAPv2, PEAP, WPA3-Enterprise, WPA3, AES-GCMP, EAP-TTLS, EAP-FAST
MAC address filtering: Yes
Network address translation (NAT): Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Quality of Service (QoS) support: Yes
Syslog: Yes
Multicast Listener Discovery (MLD) snooping: Y
Multicast support: Yes
Traffic shaping: Yes
IGMP snooping: Yes
Reset button: Yes
DHCPv6 snooping: Yes
Weight & dimensions
Height: 44 mm
Depth: 190 mm
Width: 293 mm
Weight: 790 g
Network
Data network: 5G, HSPA, 3G, UMTS, 4G
Mobile network generation: 5G
Wi-Fi: No
Load balancing: Yes
Dynamic DNS (DDNS): Yes
Networking standards: IEEE 802.3q
Modulation: 256-QAM, 1024-QAM
Ethernet LAN data rates: 100 Mbit/s, 10, 1000
PPTP/L2TP VPN tunnels (max): 25
Performance
Control display unit: No
Packaging data
Package width: 210 mm
Package depth: 320 mm
Package weight: 1.97 kg
Package height: 110 mm
Packaging content
AC adapter included: Yes
Cables included: LAN (RJ-45)
Quick start guide: Yes
Supported protocols: Ethernet over GRE-Tunnel (EoGRE), L2TPv3, ARP-Lookup, LLDP, DHCP option 82,
IPv6-Router-Advertisement-Snooping, DHCPv6-Snooping, LDRA (Lightweight DHCPv6 Relay Agent), Spanning Tree,
Rapid Spanning Tree, ARP, Proxy ARP, BOOTP, DHCP, LACP
Protocols
Routing protocols: LISP, BGP4, OSPFv2, VRRP, RIP-2
DMZ support: Yes
VoIP protocols: SIP ALG
DHCP server: Yes
Management protocols: SNMPv1,v2c,v3
DHCP client: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 5
USB 2.0 ports quantity: 1
DC-in jack: Yes
WAN connection: Ethernet (RJ-45)
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Germany
Sustainability
Sustainability compliance: Yes
