Features
Antennas quantity: 2
Antenna gain level (max): 2 dBi
Antenna connector type: SMA
Antenna type: External
Design
LED indicators: LAN, DSL, Power, WLAN, WAN
Number of fans: 1 fan(s)
Product colour: Black
Power
Power consumption (max): 36 W
Power consumption (idle): 18 W
Heat dissipation: 144 BTU/h
Security
Password protection: Yes
Security algorithms: WPA2-Enterprise, AES-CCMP, WPA3, AES-GCMP, WPA3-Enterprise, WPA, WEP, 802.1x RADIUS, MSCHAPv2, EAP-TTLS, EAP-TLS, EAP-GTC, TKIP, EAP-MD5, EAP-FAST
VLAN support: Yes
MAC address filtering: Yes
Access Control List (ACL): Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
DHCPv6 snooping: Yes
Quality of Service (QoS) support: Yes
IGMP snooping: Yes
Reset button: Yes
Syslog: Yes
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
Traffic shaping: Yes
Performance management: SLA-Monitor (ICMP)
Weight & dimensions
Depth: 190 mm
Width: 293 mm
Weight: 830 g
Height: 44 mm
Network
PPTP/L2TP VPN tunnels (max): 25
WLAN data transfer rates supported: 18, 24, 54, 867 Mbit/s, 574, 36, 300 Mbit/s, 6, 1200 Mbit/s, 5.5, 2, 9, 11, 1
Networking standards: IEEE 802.11i, IEEE 802.11b, IEEE 802.1x, IEEE 802.11ax, IEEE 802.11h, IEEE 802.11a, IEEE 802.11d, IEEE 802.11v, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Wi-Fi: Yes
Modulation: 1024-QAM, 256-QAM
Ethernet LAN data rates: 1000, 100, 10
Frequency band: 2.4/5 GHz
4G bands supported: 900, 1800, 1500, 700, 2300, 2600 MHz, 2500, 3600 MHz, 2100, 800
Band steering: Yes
UMTS bands supported: 1800, 2600 MHz, 2100 MHz, 900, 800, 2500, 700
3G standards: HSPA, UMTS
4G standard: LTE
Load balancing: Yes
Mobile network generation: 4G
Dynamic DNS (DDNS): Yes
Performance
Control display unit: No
Packaging data
Package width: 210 mm
Package depth: 320 mm
Package height: 110 mm
Package weight: 1.96 kg
Packaging content
Cables included: DSL, LAN (RJ-45)
AC adapter included: Yes
Manual: Yes
Certificates
Compliance certificates: CE
Protocols
DHCP client: Yes
DHCP server: Yes
DMZ support: Yes
Routing protocols: VRRP, LISP, OSPFv2, BGP4, RIP-2
Ports & interfaces
Ethernet LAN (RJ-45) ports: 5
USB 2.0 ports quantity: 1
WAN connection: Ethernet (RJ-45), SFP
DC-in jack: Yes
SIM card slot: Yes
SIM card type: MicroSIM
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
Sustainability
Sustainability compliance: Yes
