Features
Antenna type: External
Antennas quantity: 2
Antenna gain level (max): 3 dBi
Design
Product colour: Black
LED indicators: DSL, LAN, WLAN, WAN, Power
Number of fans: 1 fan(s)
Power
Power consumption (idle): 17 W
Power consumption (max): 33 W
Heat dissipation: 132 BTU/h
Security
Firewall security: Yes
VLAN support: Yes
Access Control List (ACL): Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Security algorithms: EAP-TTLS, PEAP, WPA2, WPA2-Enterprise, AES-CCMP, 4096-bit RSA, WPA3-Enterprise, 1024-bit RSA, EAP-MD5, FIPS 140, TKIP, 2048-bit RSA, EAP-TLS, EAP-GTC, EAP-FAST, WPA3, AES-GCMP, WEP, 802.1x RADIUS, MSCHAPv2
MAC address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Management features
Traffic shaping: Yes
Performance management: ICMP
Reset button: Yes
Multicast support: Yes
IGMP snooping: Yes
DHCPv6 snooping: Yes
Syslog: Yes
Quality of Service (QoS) support: Yes
Multicast Listener Discovery (MLD) snooping: Y
Weight & dimensions
Height: 44 mm
Depth: 190 mm
Width: 293 mm
Weight: 800 g
Network
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Wi-Fi: Yes
PPTP/L2TP VPN tunnels (max): 25
Load balancing: Yes
Dynamic DNS (DDNS): Yes
Frequency band: 2.4/5 GHz
WLAN data transfer rates supported: 48, 6, 12, 24, 54, 867 Mbit/s, 574, 1200 Mbit/s, 36, 9, 18
Modulation: 1024-QAM, 256-QAM
Networking standards: IEEE 802.11g, IEEE 802.11a, IEEE 802.11d, IEEE 802.11v, IEEE 802.11i, IEEE 802.11b, IEEE 802.11n, IEEE 802.11h, IEEE 802.1Q, IEEE 802.11ax, IEEE 802.11ac
Performance
Control display unit: No
Packaging data
Package width: 210 mm
Package weight: 1.93 kg
Package height: 110 mm
Package depth: 320 mm
Packaging content
Cables included: LAN (RJ-45)
Quick start guide: Yes
AC adapter included: Yes
Certificates
Compliance certificates: CE
Protocols
Routing protocols: OSPFv2, VRRP, BGP4, LISP, RIP-2
DHCP client: Yes
DMZ support: Yes
DHCP server: Yes
Management protocols: SNMPv1,v2c,v3
Ports & interfaces
Ethernet LAN (RJ-45) ports: 5
USB 2.0 ports quantity: 1
WAN connection: Ethernet (RJ-45), SFP
DC-in jack: Yes
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
Sustainability
Sustainability compliance: Yes
