Features
Antenna gain level (max): 2 dBi
Antenna connector type: SMA
Antennas quantity: 2
Antenna type: External
Design
LED indicators: Yes
Number of fans: 1 fan(s)
Product colour: Black
Power
Power consumption (idle): 17 W
Power consumption (max): 35 W
Heat dissipation: 140 BTU/h
Security
Password protection: Yes
Security algorithms: FIPS 140, AES, SHA-1, SHA-384, SHA-512, 3DES, SHA-256
Firewall security: Yes
VLAN support: Yes
Network address translation (NAT): Yes
MAC address filtering: Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Number of VLANs: 4096
Access Control List (ACL): Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Reset button: Yes
Syslog: Yes
Multicast support: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 815 g
Width: 293 mm
Height: 44 mm
Depth: 190 mm
Network
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Dynamic DNS (DDNS): Yes
Networking standards: IEEE 802.3az, IEEE 802.1Q
Frequency band: 2.4/5 GHz
Wi-Fi: Yes
Performance
Control display unit: No
Packaging data
Package width: 210 mm
Package height: 110 mm
Package weight: 820 g
Package depth: 320 mm
Packaging content
AC adapter included: Yes
Manual: Yes
Protocols
DHCP client: Yes
VoIP protocols: SIP ALG
DMZ support: Yes
DHCP server: Yes
Management protocols: SNMPv1,v2c,v3
Ports & interfaces
USB 2.0 ports quantity: 1
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 5
WAN connection: Ethernet (RJ-45)
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
