Features
Antenna type: External
Antennas quantity: 2
Design
Rack capacity: 1U
LED indicators: Yes
Enclosure material: Metal
Product colour: Black
Number of fans: 1 fan(s)
Power
Power consumption (max): 36 W
Input voltage: 110 - 230 V
Input frequency: 50/60 Hz
Security
Security algorithms: SRTP, SNMP
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Access Control List (ACL): Yes
Network address translation (NAT): Yes
Firewall security: Yes
VLAN support: Yes
Password protection: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Web-based management: Yes
Syslog: Yes
Reset button: Yes
Traffic shaping: Yes
Multicast support: Yes
Quality of Service (QoS) support: Yes
Performance management: SLA-Monitor (ICMP)
Weight & dimensions
Width: 345 mm
Depth: 253 mm
Height: 44 mm
Weight: 2.5 kg
Network
4G standard: LTE
Networking standards: IEEE 802.1Q, IEEE 802.3az
Cabling technology: 10/100/1000Base-T(X)
3G standards: HSPA, UMTS
Mobile network generation: 4G
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
2G standards: GSM
4G bands supported: 1500, 900, 2600 MHz, 2500, 3600 MHz, 1800, 700, 2300, 2100, 800
Differentiated services (DiffServ) supported: Yes
Performance
Control display unit: No
Packaging data
Package weight: 4.14 kg
Package depth: 448 mm
Package width: 410 mm
Package height: 130 mm
Packaging content
Cables included: DSL, LAN (RJ-45)
Manual: Yes
AC adapter included: Yes
Protocols
Routing protocols: OSPFv2, BGP4, LISP, RIP-2
DHCP client: Yes
DMZ support: Yes
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 6
SIM card slot: Yes
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
Harmonized System (HS) code: 85176990
Safety warning
Warnings: Do not open the appliance housing - risk of electric shock., Avoid contact with water and moisture to prevent short circuits., Avoid contact with liquids as this may cause electric shock., Do not open the appliance - risk of electric shock., The product may emit radio waves that may interfere with other electronic devices., Dispose of in accordance with local regulations for electro-waste and batteries.
