Features
Antenna type: Internal
Design
Number of fans: 0 fan(s)
Enclosure material: Metal
Rack capacity: 1U
Product colour: Black
LED indicators: Yes
Power
Heat dissipation: 78 BTU/h
Power consumption (max): 23 W
Power consumption (idle): 9 W
Security
ARP attack prevention: Yes
Password protection: Yes
Access Control List (ACL): Yes
Security algorithms: 4096-bit RSA, SHA-512, 1024-bit RSA, SHA-256, 256-bit AES, 192-bit AES, 3DES, 128-bit AES, SHA-384
VLAN support: Yes
Firewall security: Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Number of VLANs: 4096
MAC address filtering: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Traffic shaping: Yes
Multicast support: Yes
Performance management: SLA-Monitor (ICM
Syslog: Yes
Quality of Service (QoS) support: Yes
Web-based management: Yes
Reset button: Yes
Weight & dimensions
Width: 345 mm
Height: 44 mm
Depth: 253 mm
Weight: 2.5 kg
Network
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Networking standards: IEEE 802.1Q
Performance
Control display unit: No
Packaging data
Package height: 130 mm
Package depth: 448 mm
Package width: 410 mm
Packaging content
Cables included: AC, LAN (RJ-45)
Manual: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), CE, RCM, UKCA
Supported protocols: Ethernet over GRE-Tunnel (EoGRE), L2TPv3, ARP-Lookup, LLDP, DHCP option 82,
IPv6-Router-Advertisement-Snooping, DHCPv6-Snooping, LDRA (Lightweight DHCPv6 Relay Agent), Spanning Tree,
Rapid Spanning Tree, ARP, Proxy ARP, BOOTP, DHCP, LACP
Protocols
DHCP server: Yes
Routing protocols: OSPFv2, LISP
DMZ support: Yes
DHCP client: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 6
SIM card slot: Yes
Combo SFP ports quantity: 1
DC-in jack: Yes
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Germany
