Features
Antenna type: External
Antennas quantity: 4
Design
Mounting type: Desktop/Wall mounting
Product colour: Black
Number of fans: 1 fan(s)
Power
Power consumption (max): 27 W
Input voltage: 110 - 230 V
Heat dissipation: 92 BTU/h
Input frequency: 50 - 60 Hz
Security
VLAN support: Yes
Network address translation (NAT): Yes
Number of VLANs: 4096
Firewall security: Yes
Password protection: Yes
Access Control List (ACL): Yes
Security algorithms: SNMPv3, SNMP, SNMPv2
MAC address filtering: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 253 mm
Width: 345 mm
Height: 44 mm
Weight: 2.5 kg
Network
Cabling technology: 10/100/1000Base-T(X)
Data network: UMTS, 5G, HSPA, LTE
GSM bands supported: 800, 1900 MHz, 1800, 2100 MHz, 900, 2600 MHz, 850
Dynamic DNS (DDNS): Yes
Mobile network generation: 5G
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Performance
Control display unit: No
Protocols
DHCP client: Yes
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 6
Number of simultaneous SIM cards: 2
Combo SFP ports quantity: 1
USB 2.0 ports quantity: 1
SIM card slot: Yes
Console port: RJ-45
SIM card type: MiniSIM
WAN connection: Ethernet (RJ-45)
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Germany
