Features
Antenna type: External
Antennas quantity: 4
Design
Product colour: Black
Mounting type: Desktop/Wall mounting
Number of fans: 1 fan(s)
Power
Heat dissipation: 129 BTU/h
Input voltage: 110 - 230 V
Input frequency: 50 - 60 Hz
Power consumption (max): 38 W
Security
MAC address filtering: Yes
Network address translation (NAT): Yes
Number of VLANs: 4096
Security algorithms: SNMP, SNMPv2, SNMPv3
Firewall security: Yes
VLAN support: Yes
Access Control List (ACL): Yes
Password protection: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 345 mm
Height: 44 mm
Depth: 253 mm
Weight: 2.5 kg
Network
Mobile network generation: 5G
Ethernet LAN data rates: 10, 1000, 100 Mbit/s
GSM bands supported: 1900 MHz, 900, 2600 MHz, 2100 MHz, 1800, 800, 850
Cabling technology: 10/100/1000Base-T(X)
Data network: UMTS, LTE, HSPA, 5G
Dynamic DNS (DDNS): Yes
Performance
Control display unit: No
Protocols
DHCP client: Yes
DHCP server: Yes
Ports & interfaces
Number of simultaneous SIM cards: 2
SIM card type: MiniSIM
WAN connection: Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports: 6
USB 2.0 ports quantity: 1
Combo SFP ports quantity: 1
Foreign eXchange Station (FXS) ports quantity: 4
Console port: RJ-45
SIM card slot: Yes
ISDN ports quantity: 2
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
