Features
Antenna type: Internal
Design
Number of fans: 1 fan(s)
Rack capacity: 1U
Product colour: Black
LED indicators: Yes
Power
Input frequency: 50 - 60 Hz
Heat dissipation: 116 BTU/h
Input voltage: 110 - 230 V
Power consumption (max): 34 W
Security
VLAN support: Yes
Password protection: Yes
Firewall security: Yes
Access Control List (ACL): Yes
Number of VLANs: 4096
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Management features
Multicast support: Yes
Syslog: Yes
Reset button: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 253 mm
Width: 345 mm
Height: 44 mm
Weight: 2.5 kg
Network
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Packaging data
Package height: 130 mm
Package depth: 410 mm
Package width: 448 mm
Package weight: 3.03 kg
Packaging content
Quick installation guide: Yes
Supported protocols: DNS, HTTP, HTTPS, ICMP, NTP/SNTP, PPPoE (server), RADIUS, RADSEC (secure RADIUS), RTP, SNMPv1,v2c,v3,
TFTP, TACACS+, IGMPv3;
NDP, (SLAAC), (DHCPv6), ICMPv6, DHCPv6, DNS, HTTP, HTTPS, PPPoE, RADIUS, SMTP, NTP, BGP, LISP, Syslog,
SNMPv1,v2c,v3, MLDv2, PIM, NPTv6 (NAT66), VRRPv3
Protocols
DHCP server: Yes
DMZ support: Yes
DHCP client: Yes
Ports & interfaces
Foreign eXchange Station (FXS) ports quantity: 4
Console port: RJ-45
Ethernet LAN (RJ-45) ports: 4
USB 2.0 ports quantity: 1
VDSL ports quantity: 2
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Germany
