Design
LED indicators: System, Activity, Speed, PoE, Link
Form factor: 1U
Number of fans: 1 fan(s)
Rack mounting: Yes
Housing material: Metal
Product colour: Black
Power
AC input voltage: 100 - 240 V
Power supply included: Yes
Power source: AC/PoE
AC input frequency: 50 - 60 Hz
Power consumption (max): 230 W
Security
Security algorithms: SNMPv3
MAC address filtering: Yes
IGMP proxy: Yes
Access Control List (ACL): Yes
Loop protection: Yes
DHCP features: DHCP client, DHCP relay, DHCP snooping, DHCP Option 66, DHCP Option 67, DHCP Option 82, DHCP server
IGMP snooping: Yes
Authentication type: RADIUS, IEEE 802.1x, TACACS+
SSH/SSL support: Yes
Authentication: Guest VLAN
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 154 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Configuring Location Settings (CLI): Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Height: 44 mm
Weight: 2.7 kg
Depth: 211 mm
Width: 442 mm
Network
Networking standards: IEEE 802.1ab, IEEE 802.1x, IEEE 802.3az, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1w, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3u, IEEE 802.1ad, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1Q, IEEE 802.3x
VLAN support: Yes
Number of VLANs: 4096
10G support: Yes
Port mirroring: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Virtual LAN features: MAC address-based VLAN, Voice VLAN, VLAN Identifier ( VLAN ID), MVRP, Tagged VLAN, Port-based VLAN, IP subnet–based VLAN, Private VLAN
Link aggregation: Yes
Flow control support: Yes
Performance
Noise level: 40 dB
Firmware upgradeable: Yes
Packaging data
Package weight: 4 kg
Package height: 985 mm
Package width: 470 mm
Package depth: 540 mm
Mounting brackets included: Yes
Packaging content
Cables included: AC, Serial
Quick start guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), CE
Protocols
IP Source Guard (IPSG): Yes
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 24
SFP+ module slots quantity: 2
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 24
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 32000 entries
Jumbo frames support: Yes
Switching capacity: 88 Gbit/s
Throughput: 130 Mpps
Jumbo frames: 10240
Store-and-forward: Yes
Number of static routes: 128
Static route: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 185 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 24
Multicast features
Multicast Listener Discovery (MLD) snooping: Y
Multicast support: Yes
