Design
LED indicators: Yes
Rack mounting: Yes
Product colour: Black
Reset button: Yes
Form factor: 1U
Power
Power supply included: Yes
Power source: AC
Power consumption (max): 455 W
Security
IGMP snooping: Yes
MAC address filtering: Yes
Security algorithms: SNMPv2, SNMPv3, SNMP
Password protection: Yes
DHCP features: DHCP server
Authentication type: RADIUS, TACACS+
SSH/SSL support: Yes
Access Control List (ACL): Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 299 BTU/h
Storage temperature (T-T): 0 - 50 °C
Storage relative humidity (H-H): 10 - 90%
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Traffic classification: Yes
MIB support: Y
Switch layer: L2/L3
Cloud-managed: Yes
Switch type: Managed
Weight & dimensions
Height: 44 mm
Depth: 375 mm
Weight: 4.9 kg
Width: 442 mm
Network
Networking standards: IEEE 802.3af, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.1ak, IEEE 802.1x, IEEE 802.1ad, IEEE 802.1D, IEEE 802.3z, IEEE 802.3at, IEEE 802.3u, IEEE 802.1s, IEEE 802.1Q, IEEE 802.3x
Number of VLANs: 4093
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-T, 2500BASE-T
VLAN support: Yes
10G support: No
Performance
Noise level: 48 dB
Packaging content
Quick start guide: Yes
Ports & interfaces
2.5G Ethernet (copper) ports quantity: 12
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Gigabit Ethernet (copper) ports quantity: 12
Console port: RJ-45
SFP+ module slots quantity: 4
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
Jumbo frames support: Yes
Packet buffer memory: 4 MB
MAC address table: 32 entries
Throughput: 164 Gbit/s
Jumbo frames: 10240
Store-and-forward: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
