Design
Form factor: 1U
Rack mounting: Yes
Number of fans: 1 fan(s)
Product colour: Black
Housing material: Metal
Power
AC input frequency: 50 - 60 Hz
Power consumption (max): 860 W
Power source: AC
AC input voltage: 100 - 240 V
Security
DHCP features: DHCP server, DHCP Option 82, DHCP snooping, DHCP Option 66, DHCP client, DHCP relay, DHCP Option 67
IGMP snooping: Yes
Security algorithms: SNMPv3
SSH/SSL support: Yes
Authentication type: IEEE 802.1x, RADIUS, TACACS+
IGMP proxy: Yes
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Heat dissipation: 410 BTU/h
Management features
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch layer: L3
Configuring Location Settings (CLI): Yes
Weight & dimensions
Width: 442 mm
Weight: 4.9 kg
Height: 44 mm
Depth: 375 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.1s, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.3u, IEEE 802.1x, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.1AX, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1D, IEEE 802.3z, IEEE 802.1ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.1ad
Flow control support: Yes
Virtual LAN features: MAC address-based VLAN, Private VLAN, Voice VLAN, Tagged VLAN, Port-based VLAN, VLAN Identifier ( VLAN ID), IP subnet–based VLAN
Port mirroring: Yes
Number of VLANs: 4093
Cable length detection: Yes
VLAN support: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Performance
Firmware upgradeable: Yes
Noise level: 48 dB
Packaging data
Mounting brackets included: Yes
Packaging content
Cables included: Serial, AC
Quick start guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), CE
Protocols
IP Source Guard (IPSG): Yes
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
2.5G Ethernet (copper) ports quantity: 12
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Console port: RJ-45
Basic switching RJ-45 Ethernet ports quantity: 48
Gigabit Ethernet (copper) ports quantity: 12
SFP+ module slots quantity: 4
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
Packet buffer memory: 4 MB
MAC address table: 32000 entries
Static route: Yes
Throughput: 122 Mpps
Switching capacity: 164 Gbit/s
Jumbo frames: 10240
Jumbo frames support: Yes
Store-and-forward: Yes
Number of static routes: 128
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) power per port: 90 W
Total Power over Ethernet (PoE) budget: 740 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
