Design
Product colour: Black
Form factor: 1U
Number of fans: 1 fan(s)
Housing material: Metal
Reset button: Yes
Rack mounting: Yes
Power
Power consumption (max): 55 W
AC input voltage: 100 - 240 V
Power source: AC
Power supply included: Yes
AC input frequency: 50/60 Hz
Security
Access Control List (ACL): Yes
DHCP features: DHCP snooping, DHCP Option 66, DHCP server, DHCP client, DHCP relay, DHCP Option 82, DHCP Option 67
IGMP snooping: Yes
IGMP proxy: Yes
Authentication type: RADIUS, TACACS+
SSH/SSL support: Yes
Authentication: Guest VLAN
Operational conditions
Heat dissipation: 188 BTU/h
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
Switch layer: L3
Web-based management: Yes
Switch type: Managed
Configuring Location Settings (CLI): Yes
Weight & dimensions
Weight: 4.1 kg
Depth: 300 mm
Height: 44 mm
Width: 442 mm
Network
Broadcast storm control: Yes
10G support: Yes
Number of VLANs: 4096
Networking standards: IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1ab, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.1w
VLAN support: Yes
Port mirroring: Yes
Cable length detection: Yes
Flow control support: Yes
Virtual LAN features: IP subnet–based VLAN, Port-based VLAN, MAC address-based VLAN, Tagged VLAN, Private VLAN, VLAN Identifier ( VLAN ID), MVRP
Rate limiting: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Performance
Firmware upgradeable: Yes
Noise level: 45 dB
Packaging data
Package weight: 5.52 kg
Package width: 470 mm
Package height: 100 mm
Package depth: 534 mm
Mounting brackets included: Yes
Packaging content
Quick start guide: Yes
Cables included: Serial, AC
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC)
Protocols
IP Source Guard (IPSG): Yes
GARP VLAN Registration Protocol (GVRP): Yes
Ports & interfaces
SFP+ module slots quantity: 4
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity: 48
Power connector: AC-in jack
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 36
2.5G Ethernet (copper) ports quantity: 12
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Jumbo frames support: Yes
MAC address table: 32000 entries
Packet buffer memory: 4 MB
Throughput: 130 Mpps
Switching capacity: 212 Gbit/s
Jumbo frames: 10240
Number of static routes: 128
Store-and-forward: Yes
Static route: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Number of multicast groups filtered: 1024
Multicast Listener Discovery (MLD) snooping: Y
Safety warning
Warnings: Ensure the unit is adequately ventilated during operation., Do not open the case or try to repair it yourself., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations.
