Design
Reset button: Yes
Product colour: Black
Number of fans: 1 fan(s)
Form factor: 1U
Rack mounting: Yes
Housing material: Metal
Power
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power source: AC/PoE
Power supply included: Yes
Power consumption (max): 870 W
Security
Access Control List (ACL): Yes
Authentication type: RADIUS, TACACS+
IGMP proxy: Yes
SSH/SSL support: Yes
DHCP features: DHCP client, DHCP relay, DHCP server, DHCP Option 67, DHCP Option 82, DHCP snooping, DHCP Option 66
IGMP snooping: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 444 BTU/h
Operating temperature (T-T): 0 - 40 °C
Management features
Switch type: Managed
Configuring Location Settings (CLI): Yes
Web-based management: Yes
Switch layer: L3
Quality of Service (QoS) support: Yes
Weight & dimensions
Height: 44 mm
Width: 442 mm
Depth: 375 mm
Weight: 5.5 kg
Network
Virtual LAN features: Tagged VLAN, MVRP, MAC address-based VLAN, Voice VLAN, IP subnet–based VLAN, Private VLAN
Broadcast storm control: Yes
Link aggregation: Yes
Networking standards: IEEE 802.1ad, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.3bz, IEEE 802.1AX, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1w, IEEE 802.3af, IEEE 802.3az, IEEE 802.1s, IEEE 802.1ab, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3u
Spanning tree protocol: Yes
Flow control support: Yes
Port mirroring: Yes
10G support: Yes
Number of VLANs: 4093
Cable length detection: Yes
Performance
Firmware upgradeable: Yes
Noise level: 50 dB
Packaging data
Package width: 470 mm
Package height: 100 mm
Mounting brackets included: Yes
Package depth: 534 mm
Package weight: 6.16 kg
Packaging content
Cables included: AC, Serial
Quick start guide: Yes
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC)
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
IP Source Guard (IPSG): Yes
Ports & interfaces
SFP+ module slots quantity: 4
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 36
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 12
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Static route: Yes
Store-and-forward: Yes
Jumbo frames: 10240
Throughput: 130 Mpps
Jumbo frames support: Yes
MAC address table: 32000 entries
Switching capacity: 212 Gbit/s
Packet buffer memory: 4 MB
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 740 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast Listener Discovery (MLD) snooping: Y
Multicast support: Yes
