Design
Number of fans: 3 fan(s)
Product colour: Black
Ventilation system: Front-to-back airflow
Stackable: Yes
Rack mounting: Yes
Housing material: Metal
LED indicators: Yes
Form factor: 1U
Power
AC input frequency: 50/60 Hz
Power supply included: Yes
AC input voltage: 100 - 240 V
Power source: AC
Power consumption (max): 70 W
Security
Authentication type: RADIUS, TACACS+
IGMP proxy: Yes
DHCP features: DHCP server, DHCP client, DHCP relay, DHCP snooping
IGMP snooping: Yes
SSH/SSL support: Yes
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): 0 - 50 °C
Heat dissipation: 240 BTU/h
Management features
Web-based management: Yes
ARP inspection: Yes
Cloud-managed: Yes
Switch layer: L3
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Height: 44 mm
Weight: 5.5 kg
Depth: 373 mm
Width: 442 mm
Network
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Rate limiting: Yes
Number of VLANs: 4093
VLAN support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Networking standards: IEEE 802.3ad, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3u, IEEE 802.3bj, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1x, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1v, IEEE 802.1ad, IEEE 802.1ab, IEEE 802.1Qav
Port mirroring: Yes
Policy-based routing: Yes
10G support: No
Flow control support: Yes
Performance
Firmware upgradeable: Yes
Noise level: 50 dB
Packaging content
Rack mount kit: Yes
Cables included: Micro-USB, AC, Serial
Manual: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 30
Gigabit Ethernet (copper) ports quantity: 12
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
QSFP+ module slots quantity: 2
Console port: RJ-45/micro-USB
2.5G Ethernet (copper) ports quantity: 12
SFP+ module slots quantity: 4
USB 2.0 ports quantity: 1
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Store-and-forward: Yes
Jumbo frames: 12288
Throughput: 324 Gbit/s
Jumbo frames support: Yes
Static route: Yes
Packet buffer memory: 4 MB
MAC address table: 32000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
