Design
Stackable: Yes
Rack mounting: Yes
Form factor: 1U
Number of fans: 3 fan(s)
Housing material: Metal
Ventilation system: Front-to-back airflow
Product colour: Black
LED indicators: Yes
Power
Power supply included: Yes
Power consumption (max): 800 W
AC input frequency: 50/60 Hz
Power source: AC
AC input voltage: 100 - 240 V
Security
IGMP proxy: Yes
Authentication type: RADIUS, TACACS+
IGMP snooping: Yes
SSH/SSL support: Yes
DHCP features: DHCP server, DHCP snooping, DHCP client, DHCP relay
Access Control List (ACL): Yes
Operational conditions
Storage temperature (T-T): 0 - 50 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 205 BTU/h
Management features
Cloud-managed: Yes
ARP inspection: Yes
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Width: 442 mm
Height: 44 mm
Weight: 5.5 kg
Depth: 373 mm
Network
Link aggregation: Yes
Spanning tree protocol: Yes
Policy-based routing: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.3ac, IEEE 802.1ad, IEEE 802.3ak, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ab, IEEE 802.1Qav, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3bj, IEEE 802.3at, IEEE 802.1x, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1v, IEEE 802.3u, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae
Port mirroring: Yes
VLAN support: Yes
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Flow control support: Yes
10G support: No
Number of VLANs: 4093
Broadcast storm control: Yes
Rate limiting: Yes
Performance
Noise level: 60 dB
Firmware upgradeable: Yes
Packaging content
Rack mount kit: Yes
Cables included: Micro-USB, AC, Serial
Manual: Yes
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 12
Console port: RJ-45/micro-USB
QSFP+ module slots quantity: 2
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity: 30
2.5G Ethernet (copper) ports quantity: 12
USB 2.0 ports quantity: 1
SFP+ module slots quantity: 4
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
Store-and-forward: Yes
Jumbo frames: 12288
Throughput: 324 Gbit/s
Static route: Yes
MAC address table: 32000 entries
Packet buffer memory: 4 MB
Jumbo frames support: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 720 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
