Design
Ventilation system: Front-to-back airflow
Form factor: 1U
Stackable: Yes
Housing material: Metal
Number of fans: 3 fan(s)
Rack mounting: Yes
LED indicators: Yes
Product colour: Black
Power
Power source: AC
Power supply included: Yes
Power consumption (max): 1520 W
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Security
SSH/SSL support: Yes
Authentication type: RADIUS, TACACS+
IGMP proxy: Yes
Access Control List (ACL): Yes
DHCP features: DHCP server, DHCP snooping, DHCP client, DHCP relay
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 205 BTU/h
Management features
Cloud-managed: Yes
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Switch layer: L3
Switch type: Managed
Web-based management: Yes
Weight & dimensions
Depth: 373 mm
Height: 44 mm
Width: 442 mm
Weight: 5.5 kg
Network
Number of VLANs: 4093
Link aggregation: Yes
Spanning tree protocol: Yes
10G support: No
Broadcast storm control: Yes
Flow control support: Yes
Rate limiting: Yes
Policy-based routing: Yes
VLAN support: Yes
Port mirroring: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3ac, IEEE 802.1ab, IEEE 802.1Qav, IEEE 802.3at, IEEE 802.1x, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1v, IEEE 802.3u, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ad, IEEE 802.3ak, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3bj
Ethernet LAN data rates: 100,2500 Mbit/s
Performance
Noise level: 60 dB
Firmware upgradeable: Yes
Packaging content
Rack mount kit: Yes
Cables included: Serial, Micro-USB, AC
Manual: Yes
Ports & interfaces
2.5G Ethernet (copper) ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
QSFP+ module slots quantity: 2
Console port: RJ-45/micro-USB
Basic switching RJ-45 Ethernet ports quantity: 30
SFP+ module slots quantity: 4
USB 2.0 ports quantity: 1
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
Store-and-forward: Yes
Jumbo frames: 12288
Static route: Yes
Throughput: 360 Gbit/s
Packet buffer memory: 4 MB
Jumbo frames support: Yes
MAC address table: 32000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 90 W
Total Power over Ethernet (PoE) budget: 720 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
