Design
Number of fans: 3 fan(s)
Rack mounting: Yes
Housing material: Metal
LED indicators: Yes
Form factor: 1U
Product colour: Black
Stackable: Yes
Ventilation system: Front-to-back airflow
Power
Power consumption (max): 82 W
AC input frequency: 50 - 60 Hz
Power supply included: Yes
Power source: AC
AC input voltage: 100 - 240 V
Security
DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping
Authentication type: RADIUS, TACACS+
SSH/SSL support: Yes
IGMP snooping: Yes
IGMP proxy: Yes
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): 0 - 50 °C
Heat dissipation: 280 BTU/h
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Cloud-managed: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Width: 442 mm
Weight: 6.3 kg
Depth: 440 mm
Height: 44 mm
Network
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Networking standards: IEEE 802.1ab, IEEE 802.1Qav, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1v, IEEE 802.1ad, IEEE 802.3ak, IEEE 802.3u, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3bj, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae
VLAN support: Yes
Number of VLANs: 4093
10G support: No
Port mirroring: Yes
Policy-based routing: Yes
Spanning tree protocol: Yes
Rate limiting: Yes
Link aggregation: Yes
Flow control support: Yes
Broadcast storm control: Yes
Performance
Firmware upgradeable: Yes
Noise level: 50 dB
Packaging content
Cables included: Micro-USB, AC, Serial
User guide: Yes
Rack mount kit: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 54
USB 2.0 ports quantity: 1
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
QSFP+ module slots quantity: 2
Console port: RJ-45/micro-USB
Gigabit Ethernet (copper) ports quantity: 36
2.5G Ethernet (copper) ports quantity: 12
SFP+ module slots quantity: 4
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Jumbo frames support: Yes
MAC address table: 32000 entries
Packet buffer memory: 4 MB
Static route: Yes
Store-and-forward: Yes
Throughput: 372 Gbit/s
Jumbo frames: 12288
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
