Design
Form factor: 1U
Number of fans: 3 fan(s)
Product colour: Black
Ventilation system: Front-to-back airflow
Rack mounting: Yes
Housing material: Metal
LED indicators: Yes
Stackable: Yes
Power
Power consumption (max): 1650 W
AC input frequency: 50 - 60 Hz
Power source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
Security
IGMP proxy: Yes
DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping
IGMP snooping: Yes
Authentication type: RADIUS, TACACS+
SSH/SSL support: Yes
Access Control List (ACL): Yes
Operational conditions
Storage temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Heat dissipation: 715 BTU/h
Management features
Quality of Service (QoS) support: Yes
Web-based management: Yes
Cloud-managed: Yes
ARP inspection: Yes
Switch layer: L3
Switch type: Managed
Weight & dimensions
Height: 44 mm
Weight: 6.3 kg
Depth: 440 mm
Width: 442 mm
Network
Networking standards: IEEE 802.1p, IEEE 802.3x, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3at, IEEE 802.1ak, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.1Qbb, IEEE 802.1v, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Qav, IEEE 802.3bj, IEEE 802.3ad, IEEE 802.1Q, IEEE 802.1ad
10G support: No
Ethernet LAN data rates: 1000,100,2500 Mbit/s
VLAN support: Yes
Link aggregation: Yes
Policy-based routing: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Port mirroring: Yes
Rate limiting: Yes
Number of VLANs: 4093
Flow control support: Yes
Performance
Noise level: 60 dB
Firmware upgradeable: Yes
Packaging content
User guide: Yes
Cables included: Micro-USB, Serial, AC
Rack mount kit: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 54
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 12
USB 2.0 ports quantity: 1
QSFP+ module slots quantity: 2
Gigabit Ethernet (copper) ports quantity: 36
Console port: RJ-45/micro-USB
SFP+ module slots quantity: 4
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Jumbo frames support: Yes
Jumbo frames: 12288
Throughput: 372 Gbit/s
Store-and-forward: Yes
Packet buffer memory: 4 MB
MAC address table: 32000 entries
Static route: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 720 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
