Design
Stackable: Yes
Rack mounting: Yes
Ventilation system: Front-to-back airflow
Form factor: 1U
Number of fans: 3 fan(s)
Housing material: Metal
LED indicators: Yes
Product colour: Black
Power
Power consumption (max): 1650 W
Power source: AC
Power supply included: Yes
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Security
SSH/SSL support: Yes
DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping
IGMP snooping: Yes
IGMP proxy: Yes
Authentication type: RADIUS, TACACS+
Access Control List (ACL): Yes
Operational conditions
Storage temperature (T-T): 0 - 50 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 715 BTU/h
Management features
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Switch layer: L3
Switch type: Managed
Web-based management: Yes
Cloud-managed: Yes
Weight & dimensions
Weight: 6.3 kg
Width: 442 mm
Depth: 440 mm
Height: 44 mm
Network
Flow control support: Yes
VLAN support: Yes
10G support: No
Number of VLANs: 4093
Policy-based routing: Yes
Port mirroring: Yes
Spanning tree protocol: Yes
Rate limiting: Yes
Broadcast storm control: Yes
Link aggregation: Yes
Networking standards: IEEE 802.1ab, IEEE 802.1Qav, IEEE 802.3at, IEEE 802.1ad, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3bj, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1w, IEEE 802.3ac, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1v, IEEE 802.3u, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak
Ethernet LAN data rates: 1000,100,2500 Mbit/s
Performance
Noise level: 60 dB
Firmware upgradeable: Yes
Packaging content
User guide: Yes
Rack mount kit: Yes
Cables included: AC, Serial, Micro-USB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 54
Console port: RJ-45/micro-USB
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
SFP+ module slots quantity: 4
USB 2.0 ports quantity: 1
2.5G Ethernet (copper) ports quantity: 48
QSFP+ module slots quantity: 2
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
Packet buffer memory: 4 MB
MAC address table: 32000 entries
Static route: Yes
Jumbo frames: 12288
Store-and-forward: Yes
Throughput: 480 Gbit/s
Jumbo frames support: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 720 W
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
