Features
Antenna type: External
Antenna gain level (max): 2 dBi
Antennas quantity: 4
Design
International Protection (IP) code: IP50
LED indicators: Yes
Product colour: White
Enclosure material: Metal
Power
Power consumption (typical): 5.6 W
Power consumption (max): 11.3 W
Security
MAC address filtering: Yes
Network address translation (NAT): Yes
VLAN support: Yes
Password protection: Yes
Security algorithms: SNMPv2, HTTPS, SNMP, SNMPv3
Firewall security: Yes
Number of VLANs: 4096
Access Control List (ACL): Yes
Authentication method: PAP, CHAP, MS-CHAP, MS-CHAPv2
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -20 - 50 °C
Management features
Reset button: Yes
Quality of Service (QoS) support: Yes
Performance management: SLA-Monitor (ICMP)
Multicast support: Yes
Syslog: Yes
Weight & dimensions
Height: 152 mm
Width: 33 mm
Depth: 210 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.1Q
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Cabling technology: 10/100/1000Base-T(X)
Mobile network generation: 5G
Performance
Control display unit: No
Packaging data
Package weight: 2.15 kg
Package height: 94 mm
Package width: 385 mm
Package depth: 288 mm
Packaging content
Manual: Yes
Cables included: LAN (RJ-45)
Protocols
DHCP client: Yes
Routing protocols: BGP4, LISP, OSPFv2, RIP-2
VoIP protocols: SIP ALG
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
SIM card slot: Yes
Logistics data
Country of origin: Germany
Customs product code (TARIC): 85176200
