Design
Housing material: Metal
Product colour: Black
DIN rail mounting: Yes
Reset button: Yes
Power
Power supply included: No
Power consumption (max): 375 W
Power source: DC/PoE
Security
Access Control List (ACL): Yes
IGMP snooping: Yes
IGMP proxy: Yes
Authentication type: IEEE 802.1x, RADIUS, TACACS+
SSH/SSL support: Yes
Authentication: Guest VLAN
DHCP features: DHCP server, DHCP Option 82, DHCP Option 67, DHCP client, DHCP relay, DHCP snooping, DHCP Option 66
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 51 BTU/h
Operating temperature (T-T): -40 - 60 °C
Management features
Web-based management: Yes
Switch type: Managed
Configuring Location Settings (CLI): Yes
Quality of Service (QoS) support: Yes
Switch layer: L3
Weight & dimensions
Depth: 130 mm
Width: 70 mm
Height: 168 mm
Weight: 900 g
Network
Networking standards: IEEE 802.3u, IEEE 802.1ad, IEEE 802.3at, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.3bt, IEEE 802.1AX, IEEE 802.1w, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1p, IEEE 802.1ak
Port mirroring: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
VLAN support: Yes
Virtual LAN features: Tagged VLAN, MAC address-based VLAN, Port-based VLAN, VLAN Identifier ( VLAN ID), MVRP, IP subnet–based VLAN, Private VLAN, Voice VLAN
Cable length detection: Yes
Ethernet Ring Protection Switching (ERPS): Yes
Link aggregation: Yes
10G support: Yes
Number of VLANs: 4093
Flow control support: Yes
Performance
Firmware upgradeable: Yes
Fanless: Yes
Packaging content
Quick start guide: Yes
Cables included: Serial
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC)
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
IP Source Guard (IPSG): Yes
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 4
Console port: RJ-45
SFP+ module slots quantity: 2
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity: 8
2.5G Ethernet (copper) ports quantity: 4
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Jumbo frames support: Yes
Throughput: 51 Mpps
MAC address table: 16000 entries
Jumbo frames: 10240
Store-and-forward: Yes
Static route: Yes
Switching capacity: 68 Gbit/s
Number of static routes: 128
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 90 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Total Power over Ethernet (PoE) budget: 360 W
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
