Features
Maximum data transfer rate: 1200 Mbit/s
MIMO: Yes
2.4 GHz: Yes
5 GHz: Yes
Networking standards: IEEE 802.11a, IEEE 802.11i, IEEE 802.11b, IEEE 802.11d, IEEE 802.11v, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax, IEEE 802.11h
Channels quantity: 16 channels
VLAN support: Yes
Ethernet LAN data rates: 1000 Mbit/s, 100
Number of VLAN IDs: 4096
Maximal-Ratio Combining (MRC): Yes
MIMO type: Multi User MIMO
Maximum data transfer rate (2.4 GHz): 575 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Design
Product colour: White
LED indicators: Yes
Power
DC voltage range: 12 V
Power consumption (max): 17.3 W
Power over Ethernet (PoE): Yes
AC input voltage: 230 V
Security
Security algorithms: EAP-TTLS, EAP-TLS
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
Web-based management: Yes
Syslog: Yes
Weight & dimensions
Width: 205 mm
Height: 42 mm
Depth: 205 mm
Packaging data
Package height: 94 mm
Package weight: 11 kg
Package depth: 288 mm
Package width: 385 mm
Packaging content
Quantity per pack: 10 pc(s)
Ports & interfaces
DC-in jack: Yes
USB connector type: USB Type-A
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 1
Antenna
Antenna type: Internal
Antenna features: Integrated antenna
Antennas quantity: 2
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Germany
