Features
Virtual LAN features: Multicast VLAN
Band steering: Yes
Fast roaming: Yes
Rate limiting: Yes
Number of users: 512 user(s)
VLAN support: Yes
Automatic channel scanning: Yes
Wi-Fi roaming: Yes
Maximum data transfer rate (6 GHz): 11530 Mbit/s
Automatic channel selection: Yes
6 GHz: Yes
Maximum data transfer rate (5 GHz): 5765 Mbit/s
MIMO type: Multi User MIMO
Number of VLAN IDs: 4096
Fit AP mode features: Hotspot 2.0
Maximum data transfer rate (2.4 GHz): 1150 Mbit/s
5 GHz: Yes
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11b
Ethernet LAN data rates: 10, 10000 Mbit/s, 300 Mbit/s, 100 Mbit/s, 1000, 2500 Mbit/s, 5000
2.4 GHz: Yes
MIMO: Yes
Design
Cable lock slot type: Kensington
Placement: Ceiling, Wall
Housing material: Aluminium, Polycarbonate (PC)
Cable lock slot: Yes
Product colour: White
LED indicators: Yes
Power
Power consumption (max): 37 W
Power over Ethernet (PoE): Yes
Security
Security algorithms: WPA3-Enterprise, AES-GCMP, AES-CCMP, WPA3-Personal, EAP-TTLS, WPA2-Personal, TKIP, EAP-TLS, WEP, WPA2-Enterprise, EAP-FAST
IGMP snooping: Yes
Service Set Identifier (SSID) features: Multiple SSIDs
Number of SSID supported: 32
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 40 °C
Management features
Syslog: Yes
Web-based management: Yes
Weight & dimensions
Depth: 270 mm
Width: 270 mm
Height: 65 mm
Packaging content
Quantity per pack: 1 pc(s)
Protocols
Supported network protocols: LLDP, Proxy ARP, LACP, L2TPv3, IPv4, IPv6
Ports & interfaces
USB connector type: USB Type-A
Ethernet LAN (RJ-45) ports: 2
Antenna
Antenna gain level (max): 6 dBi
Antenna type: Internal
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
